Omron CP2E User Manual

2
Ethernet
ports
4
FB
Ethernet Send/Receive Data
Reduce programming time by Ethernet
Send/Receive Data FB to easily
exchange data between controllers.
Improved connectivity for ethernet and serial devices
Ready for Machine to Machine communication
Connect machines to networks to collect field data.
Two built-in Ethernet ports eliminate the need for switching hubs. One port is connected to the host,
and another can be connected to an HMI, PLC, or PC running support software or reserved.
Machine to Machine connectivity
Note: The L2 Switching Hub function is built in.
Two Ethernet ports on the CP2E share the same IP address.
Improve design efficiency and productivity
reducing development time with
a modular conception of the machine
Assembling lines
MES connection
CP2E-N
CP2E-N
CP2E-N
Ethernet
Ethernet
NB
Host and HMI connectivity
CP2E-N

Omron CP2E Specifications

General

Expansion I/O Units	Up to 7 units
Model	CP2E
Type	Programmable Logic Controller (PLC)
Analog Inputs	Available via expansion units
Analog Outputs	Available via expansion units
Communication Ports	RS-232C
Ethernet Port	Yes
Power Supply	100 to 240 VAC or 24 VDC (depending on the model)
