< Transistor Output Units >
Corresponding CS-series Unit
Transistor Output Unit with
terminal block for 12 outputs.
Replace this unit with a
Transistor Output Unit with 16
outputs.
2) Output points (12 points → 16 points)
3) No. of circuits (12 points/common x 1 circuit
→ 8 points/common x 2 circuits)
4) Output circuit specification
Output voltage range (5 to 24 VDC → 24 VDC)
5) Internal current consumption
(5 VDC: 10 mA → 170 mA,
26 VDC: 75 mA → 0 mA)
6) External power supply
(Not required → 24 VDC: 40 mA)
5 to 24 VDC, 0.3 A, Sourcing,
Terminal block, 12 outputs
12 to 24 VDC, 0.5 A, Sourcing,
Terminal block, Load short
circuit protection, 16 outputs
Transistor Output Unit with
terminal block for 16 outputs.
2) No. of circuits (16 points/common x 1 circuit
→ 8 points/common x 2 circuits)
3) Output circuit specifications
Residual voltage (1.4 V → 1.5 V)
ON response time (0.2 ms → 0.5 ms)
OFF response time (0.3 ms → 1.0 ms)
Terminal block, 16 outputs
12 to 24 VDC, 0.5 A, Sinking,
Terminal block, 16 outputs
Transistor Output Unit with
terminal block for 16 outputs.
2) No. of circuits (16 points/common x 1 circuit
→ 8 points/common x 2 circuits)
3) Output circuit specifications
Output capacity
(1 A/point, 4 A/Unit → 0.5 A/point, 5 A/Unit)
Residual voltage (0.8 V → 1.5 V)
ON response time (0.1 ms → 0.5 ms)
OFF response time (0.3 ms → 1.0 ms)
4) Internal current consumption
(5 VDC: 160 mA → 170 mA)
5) External power supply
(24 VDC: 35 mA → 40 mA)
6) Alarm output (Supported → Not supported)
Terminal block, Load short
circuit protection, 16 outputs
12 to 24 VDC, 0.5 A, Sourcing,
Terminal block, Load short
circuit protection, 16 outputs
Transistor Output Unit with
connector for 32 outputs.
1) No. of circuits (32 points/common x 1 circuit
→ 16 points/common x 2 circuits)
2) Output circuit specifications
Output voltage range
(5 to 24 VDC → 12 to 24 VDC)
Residual voltage (0.8 V → 1.5 V)
ON response time (0.1 ms → 0.5 ms)
OFF response time (0.4 ms → 1.0 ms)
3) Internal current consumption
(5 VDC: 180 mA → 270 mA)
4) External power supply (5 to 24 VDC: 110 mA
4.5 to 26.3 VDC, 0.1A, Sinking,
Connector, 32 outputs
(Group-2)
12 to 24 VDC, 0.5A, Sinking,
Connector, 32 outputs
Transistor Output Unit with
connector for 32 outputs.
*The CS1-series Unit does
not support dynamic outputs.
Use this C200H-series Unit
with CS1 or change the wiring
for static outputs.
Use the XW2Z-S011 Conversion Cable to
reuse the connecting cable.
2) Output method
(Dynamic or static mode → Static mode only)
Based on specifications in static output mode
3) No. of circuits (8 points/common x 4 circuits
→ 16 points/common x 2 circuits)
4) Output circuit specifications
Output voltage range
(5 to 24 VDC → 12 to 24 VDC)
Residual voltage (0.7 V → 1.5 V)
ON response time (0.2 ms → 0.5 ms)
OFF response time (0.6 ms → 1.0 ms)
5) Internal current consumption
(5 VDC: 220 mA → 270 mA)
6) External power supply
(5 to 24 VDC: 90 mA → 12 to 24 VDC: 50 mA)
4.5 to 26.3 VDC, 0.1 A, Sinking,
Connector, 32 outputs
(Special I/O)
12 to 24 VDC, 0.5A, Sinking,
Connector, 32 outputs
Transistor Output Unit with
connector for 32 outputs.
1) No. of circuits (32 points/common x 1 circuit
→ 16 points/common x 2 circuits)
2) Output circuit specifications
Output capacity (0.5 A/point, 5 A/Unit
→ 0.5 A/point, 2.5 A/common, 5 A/Unit)
Residual voltage (0.8 V → 1.5 V)
ON response time (0.1 ms → 0.5 ms)
OFF response time (0.3 ms → 1.0 ms)
3) Internal current consumption
Connector, Load short circuit
protection, 32 outputs (Group-2)
12 to 24 VDC, 0.5 A, Sourcing,
Connector, Load short circuit
protection, 32 outputs
