< Transistor Output Units >
C200H-series Unit
Corresponding CS-series Unit
Description
Difference
C200H-OD219
CS1W-OD261
Transistor Output Unit with
connector for 64 outputs..
1) No. of circuits (32 points/common x 2 circuits
→ 16 points/common x 4 circuits)
2) Output circuit specifications
Output voltage range
(5 to 24 VDC → 12 to 24 VDC)
Residual voltage (0.8 V → 1.5 V)
ON response time (0.1 ms → 0.5 ms)
OFF response time (0.4 ms → 1.0 ms)
3) Internal current consumption
(5 VDC: 270 mA → 390 mA)
4.5 to 26.3 VDC, 0.1 A, Sinking,
Connector, 64 outputs
(Group-2)
12 to 24 VDC, 0.3 A, Sinking,
Connector, 64 outputs
< TTL Output Unit >
C200H-series Unit
Corresponding CS-series Unit
Description
Difference
C200H-OD501
No replacement model
TTL Output Unit with connector for 32 outputs. The CS Series does not have the
same type of Unit.
Use C200H-OD501 with CS1 or use the CS1W-OD231 Transistor Output Unit or
CS1W-MD561 TTL I/O Unit instead.
5 VDC, 35 mA, Connector,
32 outputs (Special I/O)
< Triac Output Units >
C200H-series Unit
Corresponding CS-series Unit
Description
Difference
C200H-OA223
CS1W-OA201
Triac Output Unit with
terminal block for 8 outputs.
1) Terminal block
2) Output circuit specification
Max. inrush current (15 A: Pulse width 100 ms,
30 A: Pulse width 10 ms → 10 A: Pulse width
100 ms, 20 A: Pulse width 10 ms)
3) Internal current consumption
(5 VDC: 180 mA → 230 mA)
250 VAC, 1.2 A, Terminal block,
8 outputs
250 VAC, 1.2 A, Terminal block,
8 outputs
C200H-OA221
CS1W-OA201
Triac Output Unit with
terminal block for 8 outputs.
1) Terminal block
2) Output circuit specifications
Max. inrush current (No regulation → 10 A:
Pulse width 100 ms, 20 A: Pulse width 10 ms)
Residual voltage (1.2 VAC →
50 to 1200 mA: 1.5 VAC, 10 to 50 mA: 5 VAC)
OFF response time (1/2 of load frequency or
less → 1/2 of load frequency + 1 ms or less)
3) Internal current consumption
(5 VDC: 140 mA → 230 mA)
250 VAC, 1.2 A, Terminal block,
8 outputs
250 VAC, 1.2 A, Terminal block,
8 outputs
C200H-OA224
CS1W-OA211
Triac Output Unit with
terminal block for 12 outputs.
Replace this unit with a Triac
Output Unit with 16 outputs.
1) Terminal block
2) Output points (12 points → 16 points)
3) No. of circuits (12 points/common x 1 circuit
→ 8 points/common x 2 circuits)
4) Output circuit specifications
Max. switching capacity
(250 VAC 0.5 A/point, 2 A/Unit
→ 0.5 A/point, 2 A/common, 4 A/Unit)
Max. inrush current
(10A: Pulse width 100 ms, 20A: Pulse width
10 ms → 15A: Pulse width 10 ms)
Min. switching capacity
(10 VAC: 100 mA, 24 VAC: 50 mA, 100 VAC:
10 mA →75 VAC: 50 mA)
Residual voltage (50 to 500 mA: 1.5 VAC,
10 to 50 mA: 5 VAC → 1.6 VAC
5) Internal current consumption
(5 VDC: 270 mA → 406 mA)
250 VAC, 0.5 A, Terminal block,
12 outputs
250 VAC, 0.5 A, Terminal block,
16 outputs
C200H-OA222V
CS1W-OA211
Triac Output Unit with
terminal block for 12 outputs.
Replace this unit with a Triac
Output Unit with 16 outputs.
1) Terminal block
2) Output points (12 points → 16 points)
3) No. of circuits (12 points/common x 1 circuit
→ 8 points/common x 2 circuits)
4) Output circuit specifications
Max. inrush current
(No regulation → 15 A: Pulse width 10 ms)
Min. switching capacity (10 VAC: 10 mA
(resistive load)/40 mA (inductive load)
→ 75 VAC: 50 mA)
Residual voltage (1.2 VAC → 1.6 VAC)
ON response time
(1/2 of load frequency or less → 1 ms or less)
OFF response time (1/2 of load frequency or
less → 1/2 of load frequency + 1 ms or less)
5) Internal current consumption
(5 VDC: 200 mA → 406 mA)
250 VAC, 0.3 A, Terminal block,
12 outputs (CE marked)
250 VAC, 0.5 A, Terminal block,
16 outputs
