Appendix AStandard Models
96
Expansion CPU Racks
Name Specifications Model
Expansion CPU Backplane 11 slots CV500-BI111
Power Supply Unit
100 to 120/200 to 240 V
AC Output: 12 A, 5 VDC CV500-PS221
100 to 120/200 to 240 V
AC Output: 8 A, 5 VDC CVM1-PA208
24 VDC Output: 12 A, 5 VDC CV500-PS211
I/O Interface Unit For Expansion CPU Rack CV500-II101
CPU Bus Cable Length: 30 cm CV500-CN311
Length: 60 cm CV500-CN611
I/O Cable Length: 30 cm CV500-CN312
Length: 60 cm CV500-CN612
Termination Resistance Unit Mount to an I/O Expansion Unit to be used as a termina-
tor. Two Termination Resistance Units are provided the
CV500-IC101/201 I/O Control Unit.
CV500-TER01
Expansion I/O Backplanes
Name Specifications Model
Expansion I/O Backplane 11 slots CV500-BI112
6 slots CV500-BI062
4 slots CV500-BI042
11 slots (Must be connected directly to CPU Backplane.) CVM1-BI114
6 slots (Must be connected directly to CPU Backplane.) CVM1-BI064
Power Supply Unit
100 to 120/200 to 240 V
ACOutput: 12 A, 5 VDC CV500-PS221
100 to 120/200 to 240 V
AC Output: 8 A, 5 VDC CVM1-PA208
24 VDC Output: 12 A, 5 VDC CV500-PS211
I/O Interface Unit For Expansion I/O Rack CV500-II201
I/O Cable 30 cm CV500-CN312
60 cm CV500-CN612
1 m CV500-CN122
2 m CV500-CN222
10 m
CV500-CN132
30 m
CV500-CN332
50 m
CV500-CN532
I/O Cable for 1 Exp. I/O Rack 40 cm CV500-CN413
60 cm CV500-CN613
Termination Resistance Unit Mount to an I/O Expansion Unit to be used as a termina-
tor. Two Termination Resistance Units are provided the
CV500-IC101/201 I/O Control Unit.
CV500-TER01
