Omron CV500 Installation Guide

Appendix AStandard Models
97
Input Units
Name Specifications Model
Input Units DC 16 mA, 5 to 12 VDC; ON delay: 1.5
ms, OFF delay: 1.5 ms
16 pts 8 pts/common; 2 circuits 3G2A5-ID112
10 mA, 12 to 24 VDC; ON delay:
1.5 ms, OFF delay: 1.5 ms
16 pts 8 pts/common; 2 circuits 3G2A5-ID213
10 mA, 12 to 24 VDC; ON delay:
1.5 ms, OFF delay: 1.5 ms
32 pts 8 pts/common; 4 circuits 3G2A5-ID215
10 mA, 12 to 24 VDC; ON delay:
1.5 ms, OFF delay: 1.5 ms
32 pts 8 pts/common; 4 circuits 3G2A5-ID218
10 mA, 12 to 24 VDC; connector
type
32 pts 8 pts/common; 4 circuits C500-ID218CN
7 mA, 12 VDC; static; ON delay:
1.5 ms, OFF delay: 1.5 ms
64 pts 8 pts/common; 8 circuits C500-ID114
10 mA, 24 VDC; dynamic scan 64 pts --- 3G2A5-ID212
7 mA, 24 VDC; ON delay: 1.5 ms,
OFF delay: 1.5 ms
64 pts 8 pts/common; 8 circuits 3G2A5-ID219
Interrupt 10 mA, 12 to 24 VAC; ON delay: 1
ms, OFF delay: 1.5 ms (Not mount-
able to Duplex C2000H Rack)
8 pts Independent commons 3G2A5-ID216
AC 10 mA, 100 to 120 VAC; ON delay:
35 ms, OFF delay: 55 ms
16 pts 8 pts/common; 2 circuits 3G2A5-IA121
10 mA, 200 to 240 VAC; ON delay:
35 ms, OFF delay: 55 ms
16 pts 8 pts/common; 2 circuits 3G2A5-IA222
10 mA, 100 to 120 VAC; ON delay:
35 ms, OFF delay: 55 ms
32 pts 8 pts/common; 4 circuits 3G2A5-IA122
10 mA, 200 to 240 VAC; ON delay:
35 ms, OFF delay: 55 ms
32 pts 8 pts/common; 4 circuits C500-IA223
AC/DC 10 mA, 12 to 24 VAC/DC; ON
delay: 15 ms, OFF delay: 15 ms
16 pts 8 pts/common; 2 circuits 3G2A5-IM211
10 mA, 12 to 24 VAC/DC; ON
delay: 15 ms, OFF delay: 15 ms
32 pts 8 pts/common; 4 circuits 3G2A5-IM212
TTL 3.5 mA, 5 VDC; connector 32 pts 8 pts/common; 4 circuits C500-ID501CN
