Appendix AStandard Models
98
Output Units
Name Specifications Model
Output Units Contact 2 A, 250 VAC/24 VDC; with relay
sockets; 8 commons
16 pts 8 pts/common; 2 circuits 3G2A5-OC221
2 A, 250 VAC/24 VDC; with relay
sockets; all outputs independent
16 pts Independent commons 3G2A5-OC223
2 A, 250 VAC/24 VDC; with relay
sockets
32 pts 8 pts/common; 4 circuits 3G2A5-OC224
Transis-
tor
1 A, 12 to 24 VDC; no output when
external power supply is OFF
16 pts 8 pts/common; 2 circuits C500-OD217
2.1 A, 12 to 24 VDC 16 pts 8 pts/common; 2 circuits C500-OD219
1 A, 12 to 48 VDC 16 pts 16 pts/common; 1 circuit 3G2A5-OD411
50 mA, 24 VDC; all outputs inde-
pendent
16 pts Independent commons 3G2A5-OD215
0.3 A, 12 to 24 VDC 32 pts 16 pts/common; 2 circuits C500-OD218
0.3 A, 12 to 48 VDC 32 pts 16 pts/common; 2 circuits C500-OD414
0.3 A, 12 to 48 VDC; negative
common; terminal block
32 pts 32 pts/common; 1 circuit 3G2A5-OD412
0.3 A, 12 to 24 VDC; positive com-
mon
32 pts 16 pts/common; 2 circuits 3G2A5-OD212
0.3 A, 12 to 48 VDC; negative
common; connector
32 pts 16 pts/common; 2 circuits C500-OD415CN
0.1 A, 24 VDC; dynamic scan 64 pts --- 3G2A5-OD211
0.1 A, 24 VDC; static connector 64 pts 8 pts/common; 8 circuits 3G2A5-OD213
Triac 1 A, 100 to 120 VAC; with built-in
surge killer
16 pts 8 pts/common; 2 circuits 3G2A5-OA121
1 A, 100 to 240 VAC; with built-in
surge killer
16 pts 8 pts/common; 2 circuits 3G2A5-OA222
1 A, 100 to 240 VAC 24 pts 8 pts/common; 3 circuits 3G2A5-OA223
1 A, 100 to 240 VAC 32 pts 8 pts/common; 4 circuits C500-OA225
1.2 A, 100 to 240 VAC 16 pts 8 pts/common; 2 circuits C500-OA226
TTL 35 mA, 5 VDC; connector 32 pts 8 pts/common; 4 circuits C500-OD501CN
DC Input/Transistor Out-
put Unit
12 to 24-VDC inputs: 10 mA; 12 to
24-VDC outputs: 0.3 connector
16 pts
each
--- C500-MD211CN
Dummy I/O Unit
Input or output
16, 32,
or 64
points
--- 3G2A5-DUM01
I/O Power Supply Unit
Input: 100 to 120/200 to 240 V
AC Output:
2A, 24 VDC
--- CV500-IPS01
