Omron CV500 Installation Guide

Appendix AStandard Models
99
Special I/O Units
Name Specifications Model
Analog Input Unit 4 to 20 mA, 1 to 5 V; 2 inputs 2 pts 3G2A5-AD001
0 to 10 V; 2 inputs 2 pts 3G2A5-AD002
0 to 5 V; 2 inputs 2 pts 3G2A5-AD003
–10 to 10 V; 2 inputs 2 pts 3G2A5-AD004
–5 to 5 V; 2 inputs 2 pts 3G2A5-AD005
4 to 20 mA, 1 to 5 V; 4 inputs 4 pts 3G2A5-AD006
0 to 10 V; 4 inputs 4 pts 3G2A5-AD007
0 to 10 V, 0 to 20 mA (selectable); 8 inputs 8 pts C500-AD101
0 to 5 V, 0 to 10 V –5 to 5 V, –10 to 10 V, 0 to 20 mA,
–20 to 20 mA; 16 inputs
16 pts C500-AD501
Analog Output Unit 4 to 20 mA, 1 to 5 V; 2 outputs 2 pts 3G2A5-DA001
0 to 10 V; 2 outputs 2 pts 3G2A5-DA002
0 to 5 V; 2 outputs 2 pts 3G2A5-DA003
–10 to 10 V; 2 outputs 2 pts 3G2A5-DA004
–5 to 5 V; 2 outputs 2 pts 3G2A5-DA005
0 to 20 mA, 1 to 5 V/0 to 10 V (selectable); 4 outputs 4 pts C500-DA101
–10 to 10 V, 4 outputs 4 pts C500-DA103
High-speed Counter Unit 6-digit BCD; 50 kcps; one counted input; 1 pair of SV 1 pt 3G2A5-CT001
6-digit BCD; 50 kcps; one counted input; 8 pair of SV 1 pt 3G2A5-CT012
50 kcps; 7 operating modes 2 pts C500-CT021
6-digit BCD; 20 kcps; four counted inputs; 6 modes 4 pts C500-CT041
Magnetic Card Reader Unit With RS-232C interface 3G2A5-MGC01
PID Control Unit For PID control; w/Programming Console key sheet; 20-day
power backup to 25°C
3G2A5-PID01-E
Position Control Unit Position Control Unit: 3G2A5-NC101-E with input multiplier for
greater resolution and greater processing speed
3G2A5-NC103-E
Position Control Unit: For stepping motor; one axis 3G2A5-NC111-EV1
Position Control Unit: For pulse motors; two axes C500-NC222-E
Encoder Adapter 3G2A5-AE001
Teaching Box For 1 axis 3G2A5-TU001-E
Connecting Cable: To connect C500-TU002-E Teach-
ing Box to C500 NC222 E
2 m C200H-CN222
ing Box to C500-NC222-E.
4 m C200H-CN422
Connecting Cable: To connect C500-TU002-E Teaching Box to
3G2A5-NC103-E/NC111-EV1 Position Control Unit.
C500-CN422
Cam Positioner Unit External outputs: 8 pts; Words output to PC: 2 (16 pts.) C500-CP131
ASCII Unit RAM and EEPROM C500-ASC04
Ladder Program I/O Unit Has 40 instructions (same as a C20P.) Input and output points
(16 each.)
C500-LDP01-V1
ID Sensor Unit
Microwave type
General-purpose C500-IDS21
y
Long-distance C500-IDS22
For the C500-IDS02 C500-IDA02
For the C500-IDS22 C500-IDA22
Fuzzy Logic Unit 8 inputs, 2 outputs max. C500-FZ001
