Appendix AStandard Models
100
CPU Bus Units
The CV -series SYSMAC LINK, SYSMAC BUS/2, and SYSMAC NET Link Units are also classified as CPU Bus
Units. CPU Bus Units must be mounted to the proper slots on CPU or Expansion CPU Racks.
Name Specifications Model
Temperature Controller Data Link
Unit
Connects up to 64 temperature control devices via 2
ports.
CV500-TDL21
BASIC Unit Must be mounted
to CPU or CPU
RS-232C x 2
RS 422 x 1
RAM CV500-BSC11
to CPU or CPU
Expansion Rack
RS-422 x 1
EEPROM +
RAM
CV500-BSC21
RS-232C x 2
Centronics x 1
RAM CV500-BSC31
Centronics x 1
EEPROM +
RAM
CV500-BSC41
RS-232C x 2
GP IB x 1
RAM CV500-BSC51
GP-IB x 1
EEPROM +
RAM
CV500-BSC61
Personal Computer Unit Without floating-point division 4MB main memory CV500-VP213-E
8MB main memory CV500-VP217-E
With floating-point division 4MB main memory CV500-VP223-E
8MB main memory CV500-VP227-E
CPU Backplane Exclusively for the Personal Computer Unit CV500-BC105
RAM Disk Board 2MB memory CV500-MR261
PC Card Interface Board For PCMCIA 2.1 Type I and II cards CV500-MP602
Floppy Disk Drive One floppy disk drive CV500-FDD01
Two floppy disk drives CV500-FDD02
Hard Disk Unit 80-MB hard disk CV500-HDD11
Connecting Cable Used to join two Hard Disk Units CV500-CN116
Hard Disk Drive For 100 VAC CV500-HDD01
For 200 VAC CV500-HDD02
Floppy/Hard Disk Drive For 100 VAC CV500-FHD01-E
For 200 VAC CV500-FHD02-E
Backup Battery --- CV500-BAT08
Motion Control Unit 2 axes CV500-MC221
4 axes CV500-MC421
Connecting Cables Cable length: 2 m CV500-CN224
Cable length: 4 m CV500-CN424
Cable length: 6 m CV500-CN624
MC Support Software For IBM PC/AT or compatible CV500-ZN3AT1-E
