Omron CV500 Installation Guide

Appendix AStandard Models
101
Network Units and Remote I/O Units
The CV -series SYSMAC LINK, SYSMAC BUS/2, SYSMAC NET Link Units, and Ethernet Units are classified as
CPU Bus Units.
Name Specifications Model
SYSMAC LINK Unit Optical CV500-SLK11
Coaxial CV500-SLK21
Power Feeder Unit For optical SYSMAC LINK Unit C1000H-APS01
SYSMAC BUS/2 Remote I/O Master Unit Optical type CV500-RM211
Wire type CV500-RM221
Remote I/O Slave Unit Optical type CV500-RT211
Wire type CV500-RT221
Ethernet Unit Supports TCP/IP and UDP/ID CV500-ETN01
SYSMAC BUS Optical Remote I/O Master
Unit
APF/PCF 3G2A5-RM001-PEV1
Unit
PCF 3G2A5-RM001-EV1
Optical Remote I/O Slave Unit APF/ W/1 optical connector 3G2A5-RT001-PEV1
PCF W/2 optical connectors 3G2A5-RT002-PEV1
PCF W/1 optical connector 3G2A5-RT001-EV1
W/2 optical connectors 3G2A5-RT002-EV1
Optical I/O Link Unit APF/PCF 3G2A5-LK010-PE
PCF 3G2A5-LK010-E
CompoBus/D Master Unit --- CVM1-DRM21
Wired Remote I/O Master Unit --- C500-RM201
Wired Remote I/O Slave Unit --- C500-RT201
SYSMAC BUS
Optical I/O Units
DC Input No-voltage con-
tact
8 pts 100-VAC pow-
er supply
APF/PCF 3G5A2-ID001-PE
Optical I/O Units tact er supply
PCF 3G5A2-ID001-E
AC/DC 12 to 24 VAC/DC 8 pts APF/PCF 3G5A2-IM211-PE
Input PCF 3G5A2-IM211-E
AC Input 100 VAC 8 pts APF/PCF 3G5A2-IA121-PE
PCF 3G5A2-IA121-E
Contact
Output
2 A, 250 VAC/ 24
VDC
8 pts 100/200-VAC
power supply
APF/PCF 3G5A2-OC221-PE
Output VDC power supply
PCF 3G5A2-OC221-E
Triac Out-
put
100/200 VAC 8 pts APF/PCF 3G5A2-OA222-PE
put
PCF 3G5A2-OA222-E
Transistor
Output
0.3 A, 12 to 48 8 pts APF/PCF 3G5A2-OD411-PE
Output
VDC PCF 3G5A2-OD411-E
