Appendix AStandard Models
102
Miscellaneous Remote I/O System Units
Link Adapters with the suffix -P in the model number can be extended up to 200 m by using plastic-clad opti-
cal fiber cable. Those without the suffix -P in the model number can be extended up to 800 m.
Name Specifications Model
Link Adapter RS-422, 3 pcs 3G2A9-AL001
Optical (APF/PCF), 3pcs 3G2A9-AL002-PE
Optical (PCF), 3pcs 3G2A9-AL002-E
Optical (APF/PCF), RS-422, RS-232C, 1 pc each 3G2A9-AL004-PE
Optical (PCF), RS-422, RS-232C, 1 pc each 3G2A9-AL004-E
Optical (APF/PCF), optical (AGF), 1 pc each 3G2A9-AL005-PE
Optical (PCF), optical (AGF), 1 pc each 3G2A9-AL005-E
Optical (APF/PCF), optical (AGF), 2 pcs each 3G2A9-AL006-PE
Optical (PCF), optical (AGF), 2 pcs each 3G2A9-AL006-E
Optical (APF/PCF), 1 pc, RS-485 1 pc for Wired Remote
I/O system only
B500-AL007-P
Repeater APF/PCF 3G5A2-RPT01-PE
PCF 3G5A2-RPT01-E
All Plastic Optical-Fiber Cable (APF)
Name Specifications Model
Plastic Optical Fiber Cable
Cable only, 5 to 100 m in multiples of 5 m, or multiples of
200 or 500 m
3G5A2-PF002
Optical Connector A 2 pcs (brown), for plastic optical fiber 10 m long max. 3G5A2-CO001
Optical Connector B 2 pcs (black) for plastic optical fiber 8 to 20 m long 3G5A2-CO002
Plastic Optical Fiber Cable 1 m, w/optical connector A provided at both ends 3G5A2-PF101
Plastic-Clad Optical-Fiber Cable (PCF)
Name Specifications Model
Optical Fiber Cable (indoor) 0.1 m, w/connector Ambient temperature: 3G5A2-OF011
1 m, w/connector –10°
to 70
°C 3G5A2-OF101
2 m, w/connector 3G5A2-OF201
3 m, w/connector 3G5A2-OF301
5 m, w/connector 3G5A2-OF501
10 m, w/connector 3G5A2-OF111
20 m, w/connector 3G5A2-OF211
30 m, w/connector 3G5A2-OF311
40 m, w/connector 3G5A2-OF411
50 m, w/connector 3G5A2-OF511
Optical Fiber Cable
(indoor/outdoor)
1 to 500 m (order in units of 1
m)
Ambient temperature:
–10°
to 70
°C
3G5A2-OF002
501 to 800 m (order in units of
1 m)
Ambient temperature: 0°
to 55
°C (Must not be sub-
jected to direct sunlight)
To Next Page
