Omron CV500 Installation Guide

Appendix AStandard Models
103
Hard-plastic-clad Quartz Fiber Cable: H-PCF
Up to 800 m of H-PCF cable can be used between Units in the following systems: SYSMAC NET , SYSMAC LINK,
and SYSMAC BUS/2. In the SYSMAC BUS system, up to 100 m of H-PCF cable can be used between Units
whose model number suffix contains a P and up to 200 m between other Units whose model number does not
contain a P.
You can used connector-equipped cables or
assemble cables yourself. The following are required to assemble
H-PCF cable: the cable itself, Optical Connectors, Cable Assembly T ool, Cable Cutter Optical Power T ester , Head
Unit, and Master Fiber . The user must assemble and test the optical connectors. Refer to the H-PCF Installation
Manual for details.
H-PCF cables can be used at an ambient temperature of between –20° and 70°C.
H-PCF Optical Fiber Cords and Cables
Cable type Cable color Cable length Model
Two optical conductors with
fd
Black 10 meters S3200-HCLB101
feeder
50 meters S3200-HCLB501
100 meters S3200-HCLB102
500 meters S3200-HCLB502
1,000 meters S3200-HCLB103
Orange 10 meters S3200-HCLO101
50 meters S3200-HCLO501
100 meters S3200-HCLO102
500 meters S3200-HCLO502
1,000 meters S3200-HCLO103
Without feeder Black 10 m S3200-HCCB101
50 m S3200-HCCB501
100 m S3200-HCCB102
500 m S3200-HCCB502
Orange 10 m S3200-HCCO101
50 m S3200-HCCO501
100 m S3200-HCCO102
500 m S3200-HCCO502
Two-core optical cord Black 10 m S3200-HBCB101
50 m S3200-HBCB501
100 m S3200-HBCB102
500 m S3200-HBCB502
1,000 m S3200-HBCB103
