Omron CV500 Installation Guide

60
Special I/O Units
Unit Model Consumption (A)
Analog Input 3G2A5-AD001 to- AD005 0.3
3G2A5-AD006/007 0.75
C500-AD101 0.88
C500-AD501 1.2
Analog Output 3G2A5-DA001 to -DA005 0.55
C500-DA101 1.3
High-speed Counter
3G2A5-CT001 0.3
g
3G2A5-CT012 0.55
C500-CT021 0.35
C500-CT041 1.0
Magnetic Card Reader 3G2A5-MGC01-E 1.0
PID 3G2A5-PID01-E 1.4
Position Control 3G2A5-NC103-E T otal 1.4
3G2A5-TU001
3G2A5-NC111-EV1 T otal 1.0
3G2A5-TU001
3G2A5-NC121-E T otal 1.7
3G2A5-TU001
C500-NC222-E T otal 1.3
3G2A5-TU002
Cam Positioner C500-CP131 0.8
Voice C500-OV001 0.35
ASCII C500-ASC04 0.5
ID Sensor C500-IDSjj 0.4
Ladder Program I/O 3G2A5-LDP01-V1 0.8
Link Units
Unit Model Current Consumption (A)
SYSMAC NET Link CV500-SNT31 0.9
SYSMAC LINK CV500-SLK11/22 0.5
SYSMAC BUS/2
Remote I/O Master
CV500-RM211/221 0.5
CompoBus/D
Master Unit
CVM1-DRM21 0.25
Host Link Unit CV500-LK201 0.6
Ethernet Unit CV500-ETN01 1.7
BASIC CV500-BSC11/21 0.5
CV500-BSC51/61
CV500-BSC31/41 0.3
Personal Computer
Unit
CV500-VPjjj-E 2.3
Temperature
Controller Data Link
Unit
CV500-TDL21 0.5
Remote I/O Master 3G2A5-RM001-(P)EV1 0.7
C500-RM201 0.3
I/O Link 3G2A5-LK010-(P)E 0.6
