Omron DRT2 Series User Manual

6
DRT2-ID16/OD16
DRT2-ID16/OD16
Specifications
■ General Specifications
■ Input Specifications
■ Output Specifications
Item Specification
Network power voltage 11 to 25 VDC (supplied from the communications connector)
I/O power supply voltage 20.4 to 26.4 VDC (24 VDC -15% to +10%)
Noise immunity Conforms to IEC61000-4-4: 2 kV (power lines)
Vibration resistance 10 to 50 Hz, 0.7-mm double amplitude
Shock resistance
200 m/S
2
Dielectric strength 500 VAC (between isolated circuits)
Insulation resistance 20 MΩ min. (between isolated circuits)
Ambient operating temperature -10 to +55°C
Ambient operating humidity 35% to 85%
Ambient atmosphere No corrosive gases
Ambient storage temperature -20 to +65°C
Mounting method 35-mm DIN track mounting
Mounting strength 50 N (in directions other than the DIN track direction), 10 N (in the DIN track direction)
Screw tightening torque M3 (power supply, I/O terminals): 0.3 to 0.5 N•m
Item Specification
Model number DRT2-ID16 DRT2-ID16-1
Internal I/O common processing NPN PNP
Number of I/O points 16 inputs
ON voltage
15 VDC min. (between each input terminal
and V)
15 VDC min. (between each input terminal
and G)
OFF voltage
5 VDC min. (between each input terminal
and V)
5 VDC min. (between each input terminal
and G)
OFF current 1.0 mA max. per point (at 24 VDC)
Input current 6.0 mA max. per point at 24 VDC; 3.0 mA max. per point at 17 VDC
ON delay time 1.5 ms max.
OFF delay time 1.5 ms max.
Number of points per common 16 points per common
Item Specification
Model number DRT2-OD16 DRT2-OD16-1
Internal I/O common processing NPN PNP
Number of I/O points 16 outputs
Rated output current 0.5 A per point, 4.0 A per common
Residual voltage
1.2 V max. (0.5 A between each output termi-
nal and G)
1.2 V max. (0.5 A between each output termi-
nal and V)
Leakage current 0.1 mA max.
ON delay time 0.5 ms max.
OFF delay time 1.5 ms max.
Number of points per common 16 points per common

Omron DRT2 Series Specifications

General

I/O Classification	Digital I/O
Output Type	Transistor (NPN or PNP depending on model)
Protection Degree	IP20
Operating Temperature	-10 to 55 °C (with no icing or condensation)
Mounting Method	DIN Rail Mounting
Digital Inputs	Yes
Digital Outputs	Yes
Current Consumption	Varies by model
Storage Temperature	-25 to 65°C (with no icing or condensation)
Insulation Resistance	20 MΩ min. (at 500 VDC)
Vibration Resistance	10 to 57 Hz, 0.075 mm amplitude, 57 to 150 Hz
Input Type	DC input
Number of Input Points	8, 16, or 32 (depending on model)
Number of Output Points	8, 16, or 32 (depending on model)
Weight	Varies by model
Shock Resistance	150 m/s^2, 3 times each in 6 directions
Humidity Range	35% to 85% (with no condensation)
