7E2A
DC 3-wire Models / DC 4-wire (NO+NC)
Note 1. The response frequency is an average value. Measurement conditions are as follows: standard target, a distance of twice the standard
target distance between targets, and a setting distance of half the sensing distance.
2. When using any model at an ambient temperature between −40°C and −25°C and a power voltage between 30 and 32 VDC, use a load
current of 100 mA max.
3. For USA and Canada: use class 2 circuit only.
Size M18 M30
Type Shielded Non-shielded Shielded Non-shielded Non-shielded
Item
E2A-M18@S08-@@-B@
E2A-M18@S08-@@-C@
E2A-S18@S08-@@-B@
E2A-S18@S08-@@-C@
E2A-M18@N16-@@-B@
E2A-M18@N16-@@-C@
E2A-S18@N16-@@-B@
E2A-S18@N16-@@-C@
E2A-M30@S15-@@-B@
E2A-M30@S15-@@-C@
E2A-S30@S15-@@-B@
E2A-S30@S15-@@-C@
E2A-M30KN20-@@-B@
E2A-M30KN20-@@-C@
E2A-S30KN20-@@-B@
E2A-S30KN20-@@-C@
E2A-M30LN30-@@-B@
E2A-M30LN30-@@-C@
E2A-S30LN30-@@-B@
E2A-S30LN30-@@-C@
Sensing distance 8 mm±10% 16 mm±10% 15 mm±10% 20 mm±10% 30 mm±10%
Setting distance 0 to 6.4 mm 0 to 12.8 mm 0 to 12 mm 0 to 16 mm 0 to 24 mm
Differential travel 10% max. of sensing distance
Target Ferrous metal (The sensing distance decreases with non-ferrous metal.)
Standard target
(mild steel ST37)
24× 24× 1 mm 48× 48× 1 mm 45× 45× 1 mm 60× 60× 1 mm 90× 90× 1 mm
Response frequency
(See note 1.)
500 Hz 400 Hz 250 Hz 100 Hz 100 Hz
Power supply voltage
(operating voltage range)
12 to 24 VDC. Ripple (p-p): 10% max.
(10 to 32 VDC)
Current consumption
(DC 3-wire)
10 mA max.
Output type
-B models: PNP open collector
-C models: NPN open collector
Control
output
Load current
(See note 2.)
200 mA max. (32 VDC max.)
Residual voltage 2 V max. (under load current of 200 mA with cable length of 2 m)
Indicator Operation indicator (Yellow LED)
Operation mode
(with sensing object
approaching)
-B1/-C1 models: NO
-B2/-C2 models: NC
-B3/ -C3 models: NO+NC
For details, refer to the timing charts.
Protection circuit
Output reverse polarity protection, Power source circuit reverse polarity protection, Surge suppressor,
Short-circuit protection
Ambient air temperature Operating: −40° C to 70° C, Storage: −40° C to 85° C (with no icing or condensation)
Temperature influence
(See note 2.)
±10% max. of sensing distance at 23° C within temperature range of −25° C to 70° C
±15% max. of sensing distance at 23° C within temperature range of −
40° C to 70° C
Ambient humidity Operating: 35% to 95%, Storage: 35% to 95%
Voltage influence ±1% max. of sensing distance in rated voltage range ±15%
Insulation resistance 50 MΩ min. (at 500 VDC) between current carry parts and case
Dielectric strength 1,000 VAC at 50/60 Hz for 1 min between current carry parts and case
Vibration resistance 10 to 55 Hz, 1.5-mm double amplitude for 2 hours each in X, Y and Z directions
Shock resistance
1,000 m/s
2
, 10 times each in X, Y and Z directions
Standard and listings (See
note 3.)
IP67 after IEC 60529
IP69k after DIN 40050
EMC after EN60947-5-2
Connection method
Pre-wired models (standard is dia 4mm PVC cable with length = 2m).
Please see chapter 'Connectivity' for details on different cable materials and lenghts and M8 or M12 connectors.
Weight
(pak-
kaged)
Pre-wired model Approx. 160 g Approx. 280 g Approx. 280 g Approx. 370 g
Connector model Approx. 70 g Approx. 200 g Approx. 200 g Approx. 260 g
Material
Case Brass-nickel plated or stainless steel
Sensing surface PBT
Cable Standard cable is PVC dia 4mm. For other cable materials or diameters please refer to chapter 'Connectivity'
Clamping nut brass-nickel plated for brass models stainless steel for steel models
