8 Inductive Sensors
DC 2-wire Models
Note 1. The response frequency is an average value. Measurement conditions are as follows: standard target, a distance of twice the standard
target distance between targets, and a setting distance of half the sensing distance.
2. When using any model at an ambient temperature between −40°C and −25°C and a power voltage between 30 and 32 VDC, use a load
current of 50 mA max.
3. For USA and Canada: use class 2 circuit only.
Size M8 M12
Type Shielded Non-shielded Shielded Non-shielded
Item
E2A-S08@S02-D@ E2A-S08@N04-D@
E2A-M12
@
S04-D
@
E2A-S12
@
S04-D
@
E2A-M12
@
N08-D
@
E2A-S12
@
N08-D
@
Sensing distance 2 mm ± 10% 4 mm ± 10% 4 mm ± 10% 8 mm ± 10%
Setting distance 0 to 1.6 mm 0 to 3.2 mm 0 to 3.2 mm 0 to 6.4 mm
Differential travel 10% max. of sensing distance
Target Ferrous metal (The sensing distance decreases with non-ferrous metal.)
Standard target 8× 8× 1 mm 12× 12× 1 mm 12× 12× 1 mm 24× 24× 1 mm
Response frequency (See note 1.) 1,500 Hz 1,000 Hz 1,000 Hz 800 Hz
Power supply voltage
(operating voltage range)
12 to 24 VDC. Ripple (p-p): 10% max.
(10 to 32 VDC)
Leakage current 0.8 mA max.
Output type DC 2 wire type
Control
output
Load current
(See note 2.)
3 to 100 mA
Residual voltage 3 V max. (under load current of 100 mA with cable length of 2 m)
Indicator (see timing chart)
NO type: Operation indicator (Yellow), Setting indicator (Red)
NC type: Operation indicator (Yellow)
Operation mode
-D1 models: NO
-D2 models: NC
Protection circuit Surget suppressor, Short circuit protection
Ambient temperature Operating: −40° C to 70° C, Storage: −40° C to 85° C (with no icing or condensation)
Temperature influence
±10% max. of sensing distance at 23° C within temperature range of −25° C to 70° C
±15% max. of sensing distance at 23° C within temperature range of −40° C to 70° C
Ambient humidity Operating: 35% to 95%, Storage: 35% to 95%
Voltage influence ±1% max. of sensing distance in rated voltage range ±15%
Insulation resistance 50 MΩ min. (at 500 VDC) between current carry parts and case
Dielectric strength 1,000 VAC at 50/60 Hz for 1 min between current carry parts and case
Vibration resistance 10 to 55 Hz, 1.5-mm double amplitude for 2 hours each in X, Y and Z directions
Shock resistance
500 m/s
2
, 10 times each in X, Y and Z directions 1,000 m/s
2
, 10 times each in X, Y and Z directions
Standard and listings (See note 3.)
IP67 after IEC 60529
IP69k after DIN 40050
EMC after EN60947-5-2
Connection method
Pre-wired models (standard is dia 4mm PVC cable with length = 2m).
Please see chapter 'Connectivity' for details on different cable materials and lenghts and M8 or M12
connectors.
Weight
(packaged)
Pre-wired model Approx. 65 g Approx. 85 g
Connector model
M12 connector models: Approx. 20 g
M8 connector models: Approx. 15 g
Approx. 35 g
Material
Case Stainless steel Brass-nickel plated or stainless steel
Sensing surface PBT
Cable
Standard cable is PVC dia 4mm.
For other cable materials or diameters please refer to chapter 'Connectivity'
Clamping nut Brass-nickel plated
Brass-nickel plated for brass models stainless
steel for steel models
