E3NW-ECT EtherCAT Digital Sensor Communication Unit Operation Manual (E429)
A-1 Object Dictionary
A
A-1-7 Manufacturer Specific
Objects
The address connection with sensor amplifier
These object to communication sensor amplifiers.
Each object exist 1 to 30 objects by number of sensors.
The object is offset 80Hex.
Show below number of sensors and index address relation.
Writing must be performed one object at a time. There is an object for selection of multiple Sensor
Amplifier Unit numbers between 1 and 30.
The indexes for the objects are from 4F00 to 4F7F hex.
The following abbreviations are used for the applicable Sensor Amplifier Units.
• FA□0: E3NX-FA□0
• LA0: E3NC-LA0
• SA0: E3NC-SA0
• TA0: E9NC-TA0
• CA0: E3NX-CA0
• MA0: E3NX-MA0
• FAH0: E3NX-FAH0
• EA□0: E2NC-EA□0
• AA□0: E9NC-AA□0
• VA□0: E9NC-VA□0
• VD□0: E9NC-VD□0
Unit number Index
1 4000 to 407F
2 4080 to 40FF
3 4100 to 417F
4 4180 to 41FF
5 4200 to 427F
6 4280 to 42FF
7 4300 to 437F
8 4380 to 43FF
9 4400 to 447F
10 4480 to 44FF
11 4500 to 457F
12 4580 to 45FF
13 4600 to 467F
14 4680 to 46FF
15 4700 to 477F
16 4880 to 48FF
17 4800 to 487F
18 4980 to 49FF
19 4900 to 497F
20 4A80 to 4AFF
21 4A00 to 4A7F
22 4A80 to 4AFF
23 4B00 to 4B7F
24 4B80 to 4BFF
25 4C00 to 4C7F
26 4C80 to 4CFF
27 4D00 to 4D7F
28 4D80 to 4DFF
29 4E00 to 4E7F
30 4E80 to 4EFF
