A - 43
A Appendices
E3NW-ECT EtherCAT Digital Sensor Communication Unit Operation Manual (E429)
A-1 Object Dictionary
A
A-1-7 Manufacturer Specific
Objects
This object executes power tuning for the Sensor with the unit number that is specified by the index.
Set this object to 0001 hex to write data. It is always set to 0000 hex when reading data.
*1 Items with asterisks are supported from E3NW-ECT version 1.03. FA 0, FAH0, LA0, EA0 are not executed.
*2 Items with asterisks are supported from E3NW-ECT version 1.08.
You can check the version with object index 100A hex. (Refer to "A-1-4 Communication Objects" on page A-4.)
This object sets 1-point tuning and tolerance tuning of the Sensor with the unit number that is
specified by the index.
Set this object to 0001 hex to execute. It is always set to 0000 hex when reading the data.
If no sensing object is detected, it is necessary to wait at least 3 seconds after executing Full-auto
Tuning Setup.
* Items with asterisks are supported from E3NW-ECT version 1.03.
You can check the version with object index 100A hex. (Refer to "A-1-4 Communication Objects" on page A-4.)
This object executes the flashing command for the Sensor with the unit number that is specified by
the index.
Set this object to 0001 hex to write data. It is always set to 0000 hex when reading data.
* Items with asterisks are supported from E3NW-ECT version 1.03.
You can check the version with object index 100A hex. (Refer to "A-1-4 Communication Objects" on page A-4.)
During flashing operation, commands other than an SDO command that cancels flashing cannot be
received.
403D + (N-1) × 80
hex
No_01 ... 30 Power Tuning and Execute fine positioning *2
Subindex 0: Number of Entries
Range: 02 hex Unit: --- Default: 02 hex Attribute: ---
Size: 1 byte (U8) Access: RO PDO map: Not possible
Subindex 1: No_01 ... 30 Power Tuning IN1 and Fine Positioning IN1 *2
Range: 0000 to 0001 hex Unit: --- Default: --- hex Attribute: A
Size: 2 bytes (U16) Access: RW PDO map: Not possible
Subindex 2 *1: No_01 ... 30 Power Tuning IN2 and Fine Positioning IN2 *2
Range: 0000 to 0001 hex Unit: --- Default: --- hex Attribute: A
Size: 2 bytes (U16) Access: RW PDO map: Not possible
403E + (N-1) × 80
hex
No_01 ... 30 1-point Tuning and Tolerance Tuning*
Subindex 0: Number of Entries
Range: 02 hex Unit: --- Default: 02 hex Attribute: ---
Size: 1 byte (U8) Access: RO PDO map: Not possible
Subindex 1: No_01 ... 30 1-point Tuning IN1 and Tolerance Tuning*
Range: 0000 hex to 0001 hex Unit: --- Default: --- hex Attribute: A
Size: 2 bytes (U16) Access: RW PDO map: Not possible
Subindex 2*: No_01 ... 30 1-point Tuning IN2
Range: 0000 to 0001 hex Unit: --- Default: --- hex Attribute: A
Size: 2 bytes (U16) Access: RW PDO map: Not possible
4041 + (N-1) × 80
hex
No_01 ... 30 Flashing
Subindex 0: Number of Entries
Range: 02 hex Unit: --- Default: 02 hex Attribute: ---
Size: 1 byte (U8) Access: RO PDO map: Not possible
Subindex 1: No_01 ... 30 Flashing IN1
Range: 0000 to 0001 hex Unit: --- Default: --- hex Attribute: A
Size: 2 bytes (U16) Access: RW PDO map: Not possible
Subindex 2*: No_01 ... 30 Flashing IN2
Range: 0000 to 0001 hex Unit: --- Default: --- hex Attribute: A
Size: 2 bytes (U16) Access: RW PDO map: Not possible
