A - 45
A Appendices
E3NW-ECT EtherCAT Digital Sensor Communication Unit Operation Manual (E429)
A-1 Object Dictionary
A
A-1-7 Manufacturer Specific
Objects
This object sets the background suppression of the Sensor with the unit number that is specified by
the index.
This object reads the detection level (incident light level) of the Sensor Amplifier with the unit number
specified by the index.
The FA0, LA0, SA0, and TA0 cannot use this object.
This object reads the red detection level (incident light level) of the Sensor Amplifier with the unit
number specified by the index.
This object reads the green detection level (incident light level) of the Sensor Amplifier with the unit
number specified by the index.
4052 + (N-1) × 80
hex
No_01 ... 30 Background Removal
Subindex 0: Number of Entries
Range: 01 hex Unit: --- Default: 01 hex Attribute: ---
Size: 1 byte (U8) Access: RO PDO map: Not possible
Subindex 1: No_01 ... 30 Background Removal
Range: 0000 to FFFF hex Unit: --- Default: --- hex Attribute: A
Size: 2 bytes (U16) Access: RW PDO map: Not possible
Data Setting
0000 hex Background removal OFF
0001 hex Background removal ON
0002 to FFFF hex Not used.
405F + (N-1) × 80
hex
No_01 ... 30 Detection Level (CA0)
Subindex 0: Number of Entries
Range: 02 hex Unit: --- Default: 02 hex Attribute: ---
Size: 1 byte (U8) Access: RO PDO map: Not possible
Subindex 1: No_01 ... 30 Detection Level (CA0) IN1
Range: -1999 to 9999
(F831 to 270F hex)
Unit: --- Default: --- hex Attribute: A
Size: 2 bytes (INT16) Access: RO PDO map: Not possible
Subindex 2: No_01 ... 30 Detection Level (CA0) IN2
Range: -1999 to 9999
(F831 to 270F hex)
Unit: --- Default: --- hex Attribute: A
Size: 2 bytes (INT16) Access: RO PDO map: Not possible
4060 + (N-1) × 80
hex
No_01 ... 30 Color Detection Level (RED)
Subindex 0: Number of Entries
Range: 01 hex Unit: --- Default: 01 hex Attribute: ---
Size: 1 byte (U8) Access: RO PDO map: Not possible
Subindex 1: No_01 ... 30 Detection Level (RED)
Range: 0 to 9999
(0000 to 270F hex)
Unit: --- Default: --- hex Attribute: A
Size: 2 bytes (INT16) Access: RO PDO map: Not possible
4061 + (N-1) × 80
hex
No_01 ... 30 Color Detection Level (GREEN)
Subindex 0: Number of Entries
Range: 01 hex Unit: --- Default: 01 hex Attribute: ---
Size: 1 byte (U8) Access: RO PDO map: Not possible
Subindex 1: No_01 ... 30 Color Detection Level (GREEN)
Range: 0 to 9999
(0000 to 270F hex)
Unit: --- Default: --- hex Attribute: A
Size: 2 bytes (INT16) Access: RO PDO map: Not possible
