Omron E3T - Page 18

18 Standard Photoelectric Sensors
1216
90°
8
Four, M2 tapped holes
9
7
3.2
2.4
8
2.4
15
10.5
10.6
9 73.5
Two, M2 x 8
1.2
Mounting Brackets for Flat Models
E39-L119
Mounting Brackets for Flat Models
E39-L120
1216
8
13.56
3.2
2.4
2.4
8
14
22.5
4.2
(5.4)
10.6
(6.4)
13.5
1.2
With Mounting Bracket
(Example: E3T-FT11)
Material: 1.2 mm thick stainless
steel (SUS304)
Material: 1.2 mm thick stainless
steel (SUS304)
With Mounting Bracket
(Example: E3T-FT11)
Four, M2 tapped holes
Two, M2 x 8
