Datenblatt
Lichtleiterverstärker E3X-HD
E3X-HD
E3X-HD
4
Sensing Distances
Threaded Models
* The fiber length is 2 m on each side, so the sensing distance is given as 4,000 mm.
Cylindrical Models
Flat Models
Sleeve Models
Sensing
method
Sensing direction Size Model
Sensing distance (mm)
Giga mode Standard mode
High-speed
mode
Super-high-
speed mode
Through-beam
Right-angle
M4
E32-T11N 2M 2,000 1,000 700 280
E32-LT11N 2M 4,000 * 3,500 2,300 920
Straight
E32-T11R 2M 2,000 1,000 700 280
E32-LT11 2M 4,000 * 4,000 * 2,700 1,080
E32-LT11R 2M 4,000 * 3,500 2,300 920
Reflective
Right-angle
M3
E32-C31N 2M 110 50 46 14
E32-C21N 2M 290 130 90 39
M4 E32-D21N 2M 840 350 240 100
M6
E32-C11N 2M 780 350 320 100
E32-LD11N 2M 840 350 240 100
Straight
M3
E32-D21R 2M 140 60 40 16
E32-C31 2M
330 150 100 44
E32-C31M 1M
M4 E32-D211R 2M 140 60 40 16
M6
E32-D11R 2M 840 350 240 100
E32-CC200 2M 1,400 600 400 180
E32-LD11 2M 860 360 250 110
E32-LD11R 2M 840 350 240 100
Sensing
method
Size Sensing direction Model
Sensing distance (mm)
Giga mode Standard mode
High-speed
mode
Super-high-
speed mode
Through-beam
1 dia.
Top-view
E32-T223R 2M 450 250 150 60
1.5 dia. E32-T22B 2M 680 400 220 90
3 dia.
E32-T12R 2M 2,000 1,000 700 280
Side-view E32-T14LR 2M 750 450 260 100
Reflective
1.5 dia.
Top-view
E32-D22B 2M 140 60 40 16
1.5 dia. +
0.5 dia.
E32-D43M 1M 28 12 8 4
3 dia.
E32-D22R 2M 140 60 40 16
E32-D221B 2M 300 140 90 40
E32-D32L 2M 700 300 200 90
3 dia. +
0.8 dia.
E32-D33 2M 70 30 20 8
Sensing
method
Sensing direction Model
Sensing distance (mm)
Giga mode Standard mode
High-speed
mode
Super-high-
speed mode
Through-beam
Top-view E32-T15XR 2M 2,000 1,000 700 280
Side-view E32-T15YR 2M
750 450 260 100
Flat-view E32-T15ZR 2M
Reflective
Top-view E32-D15XR 2M 840 350 240 100
Side-view E32-D15YR 2M
200 100 52 24
Flat-view E32-D15ZR 2M
Sensing
method
Sensing direction Model
Sensing distance (mm)
Giga mode Standard mode
High-speed
mode
Super-high-
speed mode
Through-beam
Side-view
E32-T24R 2M 170 100 50 20
E32-T24E 2M 450 250 150 60
Top-view
E32-T33 1M 150 90 50 20
E32-T21-S1 2M 510 300 170 68
E32-TC200BR 2M 2,000 1,000 700 280
Reflective
Side-view
E32-D24R 2M 70 30 20 8
E32-D24-S2 2M 120 53 45 14
Top-view
E32-D43M 1M 28 12 8 4
E32-D331 2M 14 6 4 2
E32-D33 2M 70 30 20 8
E32-D32-S1 0.5M
63 27 18 7
E32-D31-S1 0.5M
E32-DC200F4R 2M 140 60 40 16
E32-D22-S1 2M
250 110 72 30
E32-D21-S3 2M
E32-DC200BR 2M 840 350 240 100
E32-D25-S3 2M 250 110 72 30
