Datenblatt
Lichtleiterverstärker E3X-HD
E3X-HD
5
E3X-HD
Small-spot, Reflective Models
High-power Beam Models
*1. The fiber length is 10 m on each side, so the sensing distance is given as 20,000 mm.
*2. The fiber length is 2 m on each side, so the sensing distance is given as 4,000 mm.
Narrow View Models
* The fiber length is 2 m on each side, so the sensing distance is given as 4,000 mm.
Type Spot diameter
Center
distance
(mm)
Model
Sensing distance (mm)
Giga mode Standard mode
High-speed
mode
Super-high-
speed mode
Variable spot
0.1 to 0.6 dia. 6 to 15 E32-C42 1M+E39-F3A Spot diameter of 0.1 to 0.6 mm at 6 to 15 mm.
0.3 to 1.6 dia. 10 to 30 E32-C42 1M+E39-F17 Spot diameter of 0.3 to 1.6 mm at 10 to 30 mm.
Parallel light 4 dia. 0 to 20
E32-C31 2M+E39-F3C
Spot diameter of 4 mm max. at 0 to 20 mm.
E32-C31N 2M+E39-F3C
Integrated lens
0.1 dia. 5 E32-C42S 1M Spot diameter of 0.1 mm at 5 mm.
6 dia. 50 E32-L15 2M Spot diameter of 6 mm at 50 mm.
Small-spot
0.1 dia.
7
E32-C41 1M+E39-F3A-5 Spot diameter of 0.1 mm at 7 mm.
0.5 dia.
E32-C31 2M+E39-F3A-5
Spot diameter of 0.5 mm at 7 mm.
E32-C31N 2M+E39-F3A-5
0.2 dia.
17
E32-C41 1M+E39-F3B Spot diameter of 0.2 mm at 17 mm.
0.5 dia.
E32-C31 2M+E39-F3B
Spot diameter of 0.5 mm at 17 mm.
E32-C31N 2M+E39-F3B
3 dia. 50
E32-CC200 2M+E39-F18
Spot diameter of 3 mm at 50 mm.
E32-C11N 2M+E39-F18
Type Sensing direction
Aperture
angle
Model
Sensing distance (mm)
Giga mode Standard mode
High-speed
mode
Super-high-
speed mode
Through-beam
models with
integrated lens
Right-angle 15° E32-LT11N 2M 4,000 *2 3,500 2,300 920
Top-view
10° E32-T17L 10M 20,000 *1 20,000 *1 20,000 *1 8,000
15°
E32-LT11 2M 4,000 *2 4,000 *2 2,700 1,080
E32-LT11R 2M 4,000 *2 3,500 2,300 920
Side-view 30° E32-T14 2M 4,000 *2 4,000 *2 4,000 *2 1,800
Through-beam
models with
lenses
Right-angle
12° E32-T11N 2M+E39-F1 4,000 *2 4,000 *2 4,000 *2 2,000
6° E32-T11N 2M+E39-F16 4,000 *2 4,000 *2 4,000 *2 3,600
Top-view
12° E32-T11R 2M+E39-F1 4,000 *2 4,000 *2 4,000 *2 2,000
6° E32-T11R 2M+E39-F16 4,000 *2 4,000 *2 4,000 *2 3,600
Side-view 60° E32-T11R 2M+E39-F2 1,450 800 500 200
Top-view
12° E32-T11 2M+E39-F1 4,000 *2 4,000 *2 4,000 *2 1,860
6° E32-T11 2M+E39-F16 4,000 *2 4,000 *2 4,000 *24,000 *2
Side-view 60° E32-T11 2M+E39-F2 2,300 1,320 860 320
Top-view
12° E32-T51R 2M+E39-F1 4,000 *2 4,000 *2 3,900 1,500
6° E32-T51R 2M+E39-F16 4,000 *2 4,000 *2 4,000 *24,000 *2
Side-view 60° E32-T51R 2M+E39-F2 1,400 720 500 200
Top-view
12° E32-T81R-S 2M+E39-F1 4,000 *2 4,000 *2 2,700 1,000
6° E32-T81R-S 2M+E39-F16 4,000 *2 4,000 *2 4,000 *2
1,
800
Side-view 60° E32-T81R-S 2M+E39-F2 1,000 550 360 140
Top-view
12° E32-T61-S 2M+E39-F1 4,000 *2 4,000 *2 4,000 *2 1,800
6° E32-T61-S 2M+E39-F16 4,000 *2 4,000 *2 4,000 *2 3,100
Side-view 60° E32-T61-S 2M+E39-F2 1,680 900 600 240
Top-view
12° E32-T51 2M+E39-F1-33 4,000 *2 4,000 *2 2,300 1,400
6° E32-T51 2M+E39-F16 4,000 *2 4,000 *2 4,000 *24,000 *2
Reflective
models with
integrated lens
Top-view 4° E32-D16 2M 40 to 2,800 40 to 1,400 40 to 900 40 to 480
Sensing
method
Sensing direction Aperture angle Model
Sensing distance (mm)
Giga mode Standard mode
High-speed
mode
Super-high-
speed mode
Through-beam Side-view
1.5°
E32-A03 2M
3,220 1,780 1,200 500
E32-A03-1 2M
3.4° E32-A04 2M 1,280 680 450 200
4°
E32-T24SR 2M 4,000 * 2,200 1,460 580
E32-T24S 2M 4,000 * 2,600 1,740 700
E32-T22S 2M 4,000 * 3,800 2,500 1,000
