E3X-HD
6
Models for Detection without Background Interference
Transparent Object Detection (Retro-reflective Models)
Transparent Object Detection (Limited-reflective Models)
Chemical-resistant, Oil-resistant Models
*1. The fiber length is 2 m on each side, so the sensing distance is given as 4,000 mm.
*2. Even if there is no sensing object, the Sensor will detect light that is reflected by the fluororesin.
Bending-resistant Models
Sensing method Sensing direction Model
Sensing distance (mm)
Giga mode Standard mode
High-speed
mode
Super-high-
speed mode
Limited-reflective
Flat-view
E32-L16-N 2M 0 to 15 0 to 12
E32-L24S 2M 0 to 4
Side-view E32-L25L 2M 5.4 to 9 (center 7.2)
Sensing method Feature Size Model
Sensing distance (mm)
Giga mode Standard mode
High-speed
mode
Super-high-
speed mode
Retro-reflective
Film detection M3
E32-C31 2M
+E39-F3R
+E39-RP37
250 200 ---
Square --- E32-R16 5M 150 to 1,500
Threaded
M6
E32-R21 2M 10 to 250
Hex-shaped
E32-LR11NP 2M
+E39-RP1
1,350 1,200 1,000 550
Sensing method Feature Sensing direction Model
Sensing distance (mm)
Giga mode Standard mode
High-speed
mode
Super-high-
speed mode
Limited-reflective
Small size
Flat-view
E32-L24S 2M
0 to 4
Standard
E32-L16-N 2M
0 to 15 0 to 12
Glass substrate
alignment, 70
°
C
E32-A08 2M
10 to 20 ---
Standard/long-distance
E32-A12 2M
12 to 30 ---
Side-view form
Side-view
E32-L25L 2M
5.4 to 9 (center 7.2)
Glass substrate
mapping, 70°C
Top-view
E32-A09 2M
15 to 38 ---
Sensing
method
Type Sensing direction Model
Sensing distance (mm)
Giga mode Standard mode
High-speed
mode
Super-high-
speed mode
Through-
beam
Oil-resistant Right-angle E32-T11NF 2M 4,000 *14,000 *14,000 *12,200
Chemical/oil-resistant
Top-view
E32-T12F 2M 4,000 *14,000 *14,000 *11,600
E32-T11F 2M 4,000 *14,000 *12,6001,000
Side-view E32-T14F 2M 1,400 800 500 200
Chemical/oil-resistant at
150°C
Top-view E32-T51F 2M 4,000 *1 2,800 1,800 700
Reflective
Semiconductors: Cleaning,
developing, and etching;
60
°
C
Top-view
E32-L11FP 5M
8 to 20 mm from tip of lens (Recommended sensing distance: 11 mm),
19 to 31 mm from center of mounting hole A (Recommended sensing distance: 22 mm)
Semiconductors: Resist
stripping; 85°C
E32-L11FS 5M
8 to 20 mm from tip of lens (Recommended sensing distance: 11 mm),
32 to 44 mm from center of mounting hole A (Recommended sensing distance: 35 mm)
Chemical/oil-resistant E32-D12F 2M --- *219013060
Chemical-resistant cable
E32-D11U 2M 840 350 240 100
Sensing method Size Model
Sensing distance (mm)
Giga mode Standard mode
High-speed
mode
Super-high-
speed mode
Through-beam
1.5 dia. E32-T22B 2M
680 400 220 90
M3 E32-T21 2M
M4 E32-T11 2M 2,500 1,350 900 360
Square E32-T25XB 2M 500 300 170 70
Reflective
1.5 dia. E32-D22B 2M
140 60 40 16
M3 E32-D21 2M
3 dia. E32-D221B 2M
300 140 90 40
M4 E32-D21B 2M
M6 E32-D11 2M 840 350 240 100
Square E32-D25XB 2M 240 100 60 30
