Omron E3X-NA - Heat Resistant Fiber Units

A-72 Photoelectric Sensors
Heat resistant
Features Shape
Compatible
Amplifier
Units (E3X-)
Sensing distance (mm)
(Values in parentheses: when
using the E39-F1 Lens Unit)
Standard object (mm)
Minimum sensing object
(Opaque object) Typical
Model
Permissible
bending
radius
150°C *1
Operating am-
bient tempera-
ture: -40 to
+150°C Fiber
sheath material:
Fluororesin
*1. For continuous operation, use the products within the temperature ranging from -40°C to 130°C.
NA#(V)
1.5 mm dia.
(0.03 mm dia.)
E32-ET51
35 mm
NA#F
1.5 mm dia.
(1 mm dia.)
200°C
Operating am-
bient tempera-
ture: -40 to
+200°C Flexi-
ble: R10
Fiber sheath
material: Te-
flon*2
*2. Teflon is a registered trademark of Dupont Company and Mitsui Dupont Chemical Company for their fluoride resin.
NA#(V)
1.0 mm dia.
(0.2 mm dia.)
E32-T81R
10 mm
NA#F
1.0 mm dia.
(0.5 mm dia.)
300°C *3
With spiral tube,
excellent in me-
chanical
strength Oper-
ating ambient
temperature: -
40 to +300°C
Fiber sheath
material: SUS
*3. Indicates the heat-resistant temperature at the fiber tip.
NA#(V)
1.0 mm dia.
(0.03 mm dia.)
E32-T61
25 mm
NA#F
1.0 mm dia.
(0.5 mm dia.)
150°C
Side-view
minute work de-
tection Operat-
ing ambient
temperature:
-40 to +150°C
Fiber sheath
material: Fluo-
roresin
NA#(V)
1.0 mm dia.
(0.03 mm dia.)
E32-T54
35 mm
NA#F
1.0 mm dia.
(0.3 mm dia.)
200 °C
L-shaped Fiber
sheath material:
SUS
NA#(V)
1.7 mm dia.
(0.03 mm dia.)
E32-T84S
25 mm
NA#F
1.7 mm dia.
(0.4 mm dia.)
Free-cut
M4 screw
400
120
M4 screw
180
50
M4 screw
300 (3,000)
90
Free-cut
2-mm dia.
130
35
3-mm dia.
700
210
