Omron E3X-SD Series - Page 10

E3X-SD/-NA
10
Reflective Models (Unit: mm)
Model
E3X-SD@
E3X-NA@
E3X-NA@F
Type
Standard
models
High-speed detection
models
Standard
models
Flexible
(new standard)
E32-D11R/E32-D12R/E32-D15XR/E32-DC200BR (B4R) 90 30
E32-D14LR 16 5
E32-D15YR/E32-D15ZR 20 5
E32-D211R/E32-D21R/E32-D22R/E32-D25XR/
E32-DC200FR (F4R)
15 5
E32-D24R 7 2.3
E32-D25YR/E32-D25ZR 4 1.2
Standard
E32-DC200/E32-D15X/E32-DC200B (B4) 150 50
E32-D12 120 40
E32-D14L 40 13
E32-D15Y/E32-D15Z 50 15
E32-D211/E32-DC200E/E32-D22/E32-D25X/
E32-DC200F (F4)
36 12
E32-D24 15 5
E32-D25Y/E32-D25Z 10 3.3
Break resistant
E32-D11/E32-D15XB 90 30
E32-D21B/E32-D221B 35 10
E32-D21/E32-D22B 15 5
E32-D25XB 25 8
Fluorine coating E32-D11U 90 30
Special-
beam
models
Long distance,
high power
E32-D16 40 to 400 55 to 70
E32-D11L 200 65
E32-D21L/E32-D22L 50 17
Ultracompact,
ultrafine sleeve
E32-D33 10 3.3
E32-D331 1.5 0.5
Coaxial, small spot
E32-CC200R 75 25
E32-CC200 150 50
E32-D32L 80 25
E32-C31/E32-D32 40 13
E32-C42 + E39-F3A
Spot diameter of 0.1 to 0.6 mm at
6 to 15 mm.
E32-D32 + E39-F3A
Spot diameter of 0.5 to 1 mm at
6 to 15 mm.
E32-C41 + E39-F3A-5 Spot diameter of 0.1 mm at 7 mm.
E32-C31 + E39-F3A-5 Spot diameter of 0.5 mm at 7 mm.
E32-C41 + E39-F3B Spot diameter of 0.2 mm at 17 mm.
E32-C31 + E39-F3B Spot diameter of 0.5 mm at 17 mm.
E32-C31 + E39-F3C
Spot diameter of 4 mm max. at
0 to 20 mm.
Area sensing E32-D36P1 75 25
Retro-reflective
E32-R21 + E39-R3 (provided) 10 to 250
E32-R16 + E39-R1 (provided) 150 to 1500 150 to 1000
Convergent-
reflective
E32-L25/E32-L25A 3.3
E32-L24S 0 to 4
E32-L24L 2 to 6 (center 4)
E32-L25L 5.4 to 9 (center 7.2)
E32-L86 4 to 10
E32-L16 0 to 15 0 to 13
Environ-
ment
resistive
models
Heat resistant
E32-D51 120 40
E32-D81R/E32-D61 45 15
E32-D73 30 10
Chemical resistant
E32-D12F 50 16
E32-D14F 20 6.5
For information on Fiber Units, refer to the E32 Series Fiber Sensor Best Selection (Cat. No. E354).
