E3Z-L
Safety Precautions
Refer to Warranty and Limitations of Liability.
This product is not designed or rated for ensuring
safety of persons either directly or indirectly.
Do not use it for such purposes.
Do not use the product in atmospheres or environments that exceed
product ratings.
Dimensions (Unit: mm)
Sensors
Accessories (Order Separately)
Mounting Brackets
WARNING
Precautions for Correct Use
Stability indicator
(green)
Operation indicator
(orange)
4-dia. vinyl-insulated round cable with 3 conductors
(Conductor cross section: 0.2 mm
2
;
Insulator diameter: 1.1 mm),
Standard length: 2 m
Two, M3
Receiver
Optical axis
Emitter
Sensitivity adjuster
Operation selector
20
12.45
8.8
3.2
17
2.1
25.4 31
14.8
4
18
4
10.4 10.8
4.3
Pre-wired Models
E3Z-L61
E3Z-L81
e-CON Pre-wired Connector
15
5.9
15.6
4
3
2
1
Connector: Model No.37104-3122-000FL
Sumitomo
3M
* 4-dia. vinyl-insulated round cable with 3 conductors,
Standard len
ths: 0.3 m, 0.5 m, and 2 m
Stability indicator
(green)
Operation indicator
(orange)
M8 Connector
Receiver
Optical axis
Emitter
Sensitivity adjuster
20
12.45
8.8
3.2
10.4 10.8
4.3
2.1
25.4 31
10.4
17
9.75
14.8
18
4
4
Operation selector
Two, M3
Connector Models
E3Z-L66
E3Z-L86
http://www.ia.omron.com/
4
(c)Copyright OMRON Corporation 2007 All Rights Reserved.
