E3Z-LT/LR/LL
11
Dimensions
Sensors
* Models numbers for Through-beam Sensors (E3Z-LT@@) are for sets that include both the Emitter and Receiver.
The model number of the Emitter is expressed by adding "-L" to the set model number (example: E3Z-LT61-L 2M), the model number of the Receiver, by adding "-D"
(example: E3Z-LT61-D 2M.) Refer to Ordering Information to confirm model numbers for Emitter and Receivers.
(Unit: mm)
Tolerance class IT16 applies to dimensions in this datasheet unless otherwise specified.
Through-beam＊
Pre-wired Models
E3Z-LT61
E3Z-LT81
4 dia. vinyl-insulated round cable with
2 conductors (Conductor cross section:
0.2 mm
2
(AWG24), Insulator diameter:1.1 mm),
Standard length: 2 m
Two, M 3
Power indicator
(orange)
Lens
3.5 dia.
Emitter
E3Z-LT@1-L
12
20
20
3
2.8
25.4
12.7
2.1
31
31
10.8
10.8
Two, M 3
11
Stability indicator (green)
Sensitivity adjuster
Operation selector
Lens
Receiver
E3Z-LT@1-D
4.5
11.2
7.5
20
20
3
2.8
25.4
12.7
2.1
31
31
10.8
10.8
Operation Indicator
(orange)
4 dia. vinyl-insulated round cable with
3 conductors (Conductor cross section:
0.2 mm
2
(AWG24), Insulator diameter: 1.1 mm),
Standard length: 2m
Through-beam＊
Standard Connector
Models
E3Z-LT66
E3Z-LT86
M8 4-pin connector
Two, M 3
Power indicator (orange)
9.75
Emitter
E3Z-LT@6-L
Lens 3.5 dia.
12
20
20
12.7
3
2.8
25.4
10.4
2.1
31
31
10.8
10.8
Pins 2 and 4 are not used.
Terminal No. Specifications
1+V
2 ---
30 V
4 ---
M8 4-pin connector
9.75
Lens
11
Stability indicator (green)
Sensitivity adjuster
Operation selector
Two, M 3
Receiver
E3Z-LT@6-D
Operation Indicator
(orange)
4.5
11.2
7.5
2.8
25.4
12.7
20
20
3
10.8
10.8
10.4
2.1
31
31
Pins 2 is not used.
Terminal No. Specifications
1+V
2 ---
30 V
4Output
