E3Z-LT/LR/LL
3
Mounting Brackets A Mounting Bracket is not provided with the Sensor. Order a Mounting Bracket separately if required.
(Refer to Dimensions on E39-L/E39-S/E39-R.)
Note: When using a Through-beam Sensor, order one Mounting Bracket for the Receiver and one for the Emitter
*1. Cannot be used for Standard Connector models with mounting surface on the bottom. In that case, use Pre-wired Connector models.
*2. Cannot be used for Standard Connector models.
Sensor I/O Connectors (Sockets on One Cable End)
(Models for Connectors and Pre-wired Connectors: A Connector is not provided with the Sensor. Be sure to order a Connector separately.)
(Refer to Dimensions on XS3)
Note: When using a Through-beam Sensor, order one Mounting Bracket for the Receiver and one for the Emitter
*1. The connector will not rotate after connecting.
*2. The cable is fixed at an angle of 180° from the sensor emitter/receiver surface.
Appear-
ance
Model Quantity Remarks
Appear-
ance
Model Quantity Remarks
E39-L153
*1
1
Mounting Brackets
E39-L98
*2
1 Metal Protective Cover Bracket
E39-L104
*1
1 E39-L150 1 set
(Sensor adjuster)
Easily mounted to the aluminum
frame rails of conveyors and
easily adjusted.
For left to right adjustment
E39-L43
*2
1 Horizontal Mounting Bracket
E39-L151 1 set
E39-L142
*2
1
Horizontal Protective Cover
Bracket
E39-L44 1 Rear Mounting Bracket
E39-L144
*2
1
Compact Protective Cover
Bracket (For E3Z only)
Size Cable Appearance Cable type Model
M8 Standard
2 m
4-wire
XS3F-M421-402-A
5 m XS3F-M421-405-A
2 m XS3F-M422-402-A
5 m XS3F-M422-405-A
Straight *1
L-shaped *1 *2
