Omron E3Z series Network Connection Guide

8
．
Initialization method
40
(2) Select NX-ECC202 on the EtherCAT Tab Page in the Edit Pane.
Click Edit Slave Terminal Configuration for the value of Slave Terminal Configuration.
(3) The connected Slave Terminal configuration is displayed. Click Online.
(4) Right-click Unit 0 (EtherCAT Coupler Unit) after checking the online connection.
Select Clear All Memory from the menu.

Omron E3Z series Specifications

General

Protection Rating	IP67
Response Time	1 ms or less
Accessory Type	Photoelectric Sensor
Connection Type	Pre-wired, Connector
Sensing Method	Through-beam, Retro-reflective, Diffuse-reflective
Light Source	Infrared LED, Red LED
Power Supply Voltage	12 to 24 VDC
Output Type	NPN, PNP
Operating Temperature	-25 to 55°C
Sensing Distance	varies by model (up to 30m for Through-beam)
