17
Installation Section 2-1
E5EZ
2-1-2 Panel Cutout
Unit: mm
E5CZ/CZ-U
E5AZ
60 min.
+1.0
0
Individual Mounting Group Mounting
(48 × number of Units − 2.5)
120 min.
+1.0
0
Individual Mounting Group Mounting
(96 × number of Units − 3.5)
