Digital Temperature Controllers E5EZ 9
■ Input Ranges
Platinum Resistance Thermometer Input
Thermocouple Input
Shaded setting indicates the default setting.
ES1B Infrared Temperature Sensor
Analog Input
Applicable standards by input type are as follows:
K: GB/T 2814-98
J,L: GB/T 4994-98
T,U: GB/T 2903-98
E: GB/T 4993-98
N: GB/T 17615-98
R: GB/T 1598-98
S: GB/T 3772-98
B: GB/T 2902-99
JPt100, Pt100: GB/T 5977-99
Output Modules
Communications Modules
Other Modules
Input type Pt100 JPt100
Temperature
range
−200 to
850°C
−199.9 to
500.0°C
0.0 to
100.0°C
−199.9 to
500.0°C
0.0 to
100.0°C
Setting number 01234
Input type K J T E L U N R S B
Temperature
range
−200 to
1300°C
−20 to
500°C
−100 to
850°C
−20.0 to
400.0°C
−200 to
400°C
−199.9 to
400.0°C
0 to
600°C
−100 to
850°C
−200 to
400°C
−199.9 to
400.0°C
−200 to
1300°C
0 to
1700°C
0 to
1700°C
100 to
1800°C
Setting number
5678 9221011122313141516
Input type 10 to
70°C
60 to
120°C
115 to
165°C
140 to
260°C
Setting range 0 to 90°C 0 to 120°C 0 to 165°C 0 to 260°C
Setting number 17 18 19 20
Input type 0 to 50 mV
Setting range Usable in the following ranges by scaling:
−1999 to 9999 or −199.9 to 999.9
Setting number 21
Type Model Rating and performance
Relay E53-AZR 250 VAC, 5 A (resistive load), electrical life: 100,000 operations
Voltage E53-AZQ 12 VDC, 40 mA PNP
Current E53-AZC 4 to 20 mA DC, load: 600
Ω max, resolution: approx. 2,600
Type Model Performance
RS-232C E53-AZ01 Half-duplex: 1,200/2,400/4,800/9,600/19,200 bps ASCII
RS-485 E53-AZ03 Full-duplex: 1,200/2,400/4,800/9,600/19,200 bps ASCII
Type Model Rating and performance
Option board E53-AZM Expansion for E53-AZH and E53-AZ01 or E53-AZ03 or E53-AZB
Event input E53-AZB ON: 1 K
Ω max.; OFF: 100 KΩ min.
Heater burnout detection E53-AZH Using CT to detect heater burnout
