Omron E5AC User Manual

6 Parameters
6 - 26
E5@C Digital Temperature Controllers User’s Manual (H174)
These parameters set the set points when the multi-SP function is used.
sp-0
SP 0
The Number of Multi-SP Points parameter must be
set to 2 to 8 and the Event Input 1 Assignment to
Event Input 6 Assignment parameters must not be
set to “Multi-SP No. switching bit 0” to “Multi-SP
No. switching bit 2.”
sp-1
SP 1
sp-2
SP 2
sp-3
SP 3
sp-4
SP 4
sp-5
SP 5
sp-6
SP 6
sp-7
SP 7
The values set in these parameters can be selected by operating the keys on the front panel
or by using event inputs.
• When the set point has been changed, the set value of the set point (0 to 7) selected by
the multi-SP inputs is also changed to the same value.
• The decimal point position depends on the selected sensor. During analog input, it
depends on the Decimal Point parameter setting.
 Related Parameters
Process Value/Set Point (Operation Level): Page 6-8
Input Type (Initial Setting Level): Page 6-43
Event Input Assignment (Initial Setting Level): Page 6-57
Number of Multi-SP Points (Advanced Function Setting Level): Page 6-63
Function
Setting
Setting range Unit Default
SP lower limit to SP upper limit EU 0
See
See

Omron E5AC Specifications

General

Mounting Type	Panel Mount
Sampling Period	50 ms
Protection structure	IP66 (front panel)
Control Method	ON/OFF
Input Type	Thermocouple, RTD
Supply Voltage	100 to 240 VAC
Output Type	Relay, Voltage, Current
Control Output	Relay, voltage, current
Dimensions	96 x 96 mm
Display Type	LCD
Number of Displays	2
Alarm Output	Relay
Communication	RS-485
Ambient Operating Temperature	-10 to 55°C
Ambient Operating Humidity	25% to 85% RH
