Basic-type Digital Temperature Controller E5AN/E5EN 3
Ordering Information
E5AN
Controllers with Terminal Blocks
Note: Heater alarm = heater burnout + SSR short detection + SSR overcurrent
Note: Add power supply voltage to model to complete ordering code (ie. E5AN-R3MT-500-N AC100-240 or E5AN-R3MTD-500-N AC/DC24)
Size
Case
color
Power
supply
voltage
Input type
Auxilia-
ry
outputs
Control output
1
Functions
Model
Heater
alarm
Power supply
for Sensor
Control
output 2
1/4 DIN
96 × 96 × 78
(W × H × D)
Black
100 to
240 VAC
Thermocouple
or
Resistance
thermometer
3
Relay output E5AN-R3MT-500-N
Voltage output
(for driving SSR)
E5AN-Q3MT-500-N
Current output E5AN-C3MT-500-N
Relay output 1-phase E5AN-R3HMT-500-N
Voltage output
for driving SSR)
1-phase E5AN-Q3HMT-500-N
Relay output 3-phase E5AN-R3HHMT-500-N
Voltage output
for driving SSR)
3-phase E5AN-Q3HHMT-500-N
Relay output
Voltage
output
E5AN-R3QMT-500-N
Voltage output
(for driving SSR)
Voltage
output
E5AN-Q3QMT-500-N
Current output
Voltage
output
E5AN-C3QMT-500-N
Relay output
Long-life
relay
output
E5AN-R3YMT-500-N
Voltage output
(for driving SSR)
E5AN-Q3YMT-500-N
Current output E5AN-C3YMT-500-N
Relay output Sensor Power E5AN-R3PMT-500-N
Voltage output
(for driving SSR)
Sensor Power E5AN-Q3PMT-500-N
Analog
(current/voltage)
3
Relay output E5AN-R3ML-500-N
Voltage output
(for driving SSR)
E5AN-Q3ML-500-N
Current output E5AN-C3ML-500-N
Relay output 1-phase E5AN-R3HML-500-N
Voltage output
(for driving SSR)
1-phase E5AN-Q3HML-500-N
Voltage output
(for driving SSR)
Long-life
relay
output
E5AN-Q3YML-500-N
24 VAC/
DC
Thermocouple
or
Resistance
thermometer
3
Relay output E5AN-R3MTD-500-N
Voltage output
(for driving SSR)
E5AN-Q3MTD-500-N
Current output E5AN-C3MTD-500-N
Relay output 1-phase E5AN-R3HMTD-500-N
Voltage output
(for driving SSR)
1-phase E5AN-Q3HMTD-500-N
Relay output 3-phase E5AN-R3HHMTD-500-N
Voltage output
(for driving SSR)
3-phase E5AN-Q3HHMTD-500-N
