Com Data

for Modbus

SECTION 6 Communications Data for Modbus

6-14

Note: After communications parameters have been changed, reset the Controller to enable them.

1100 3100 Protocol Setting (See note.) H'00000000 (0): CompoWay/F (SYSWAY)

H'00000001 (1): Modbus

Communi-

cations set-

ting

1102 3101 Communications Unit No. (See

note.)

H'00000000 to H'00000063 (0 to 99)

1104 3102 Communications Baud Rate

(See note.)

H'00000000 (0): 1.2

H'00000001 (1): 2.4

H'00000002 (2): 4.8

H'00000003 (3): 9.6

H'00000004 (4): 19.2

H'00000005 (5): 38.4

H'00000006 (6): 57.6

1106 3103 Communications Data Length

(See note.)

H'00000007 (7): 7

H'00000008 (8): 8

1108 3104 Communications Stop Bits (See

note.)

H'00000001 (1): 1

H'00000002 (2): 2

110A 3105 Communications Parity (See

note.)

H'00000000 (0): None

H'00000001 (1): Even

H'00000002 (2): Odd

110C 3106 Send Data Wait Time (See note.) H'00000000 to H'00000063 (0 to 99)

1200 3200 PF Setting H'00000000 (0): None

H'00000001 (1): Run

H'00000002 (2): Stop

H'00000003 (3): RUN/STOP

H'00000004 (4): 100% AT execute

H'00000005 (5): 40% AT execute

H'00000006 (6): Alarm latch cancel

H'00000007 (7): Auto/manual switch

H'00000008 (8): Monitor/setting item

Advanced

function

setting

1204 3202 Monitor/Setting Item 1 H'00000000 (0): Disabled

H'00000001 (1): PV/SP/multi-SP

H'00000002 (2): PV/SP/MV

H'00000003 (3): PV/SP/soak time remain

H'00000004 (4): Proportional band (P)

H'00000005 (5): Integral time (I)

H'00000006 (6): Derivative time (D)

H'00000007 (7): Alarm value 1

H'00000008 (8): Alarm value upper limit 1

H'00000009 (9): Alarm value lower limit 1

H'0000000A (10): Alarm value 2

H'0000000B (11): Alarm value upper limit 2

H'0000000C (12): Alarm value lower limit 2

H'0000000D (13): Alarm value 3

H'0000000E (14): Alarm value upper limit 3

H'0000000F (15): Alarm value lower limit 3

1206 3203 Monitor/Setting Item 2 H’00000000 to H’0000000F (0 to 15)

* Same as for Monitor/Setting Item 1.

Advanced

function

setting

1208 3204 Monitor/Setting Item 3 H’00000000 to H’0000000F (0 to 15)

* Same as for Monitor/Setting Item 1.

120A 3205 Monitor/Setting Item 4 H’00000000 to H’0000000F (0 to 15)

* Same as for Monitor/Setting Item 1.

120C 3206 Monitor/Setting Item 5 H’00000000 to H’0000000F (0 to 15)

* Same as for Monitor/Setting Item 1.

Address

Parameter name Setting (monitor) value LevelFour-

byte

mode

Two-

byte

mode
