Omron E5AN Communications Manual

Com Data
for Modbus
6.1 Variable Area (Setting Range) List
6-15
Note: The logic of the Modbus Write Variable operation command is not affected.
Address
Parameter name Setting (monitor) value LevelFour-
byte
mode
Two-
byte
mode
130A 3305 Cold Junction Compensa-
tion Method
H'00000000 (0): OFF
H'00000001 (1): ON
Advanced
function
setting
1314 330A α H'00000000 to H'00000064 (0.00 to 1.00)
131E 330F AT Calculated Gain H'00000001 to H'00000064 (0.1 to 10.0)
1320 3310 AT Hysteresis H'00000001 to H'0000270F
(0.1 to 999.9 for TC/Pt universal input models)
(0.01 to 9.99 for Analog input models)
1322 3311 Limit Cycle MV Amplitude H'00000032 to H'000001F4 (5.0 to 50.0)
1328 3314 Heater Burnout Latch H'00000000 (0): OFF
H'00000001 (1): ON
132A 3315 Heater Burnout Hysteresis H'00000001 to H'000001F4 (0.1 to 50.0)
132C 3316 HS Alarm Latch H'00000000 (0): OFF
H'00000001 (1): ON
132E 3317 HS Alarm Hysteresis H'00000001 to H'000001F4 (0.1 to 50.0)
1334 331A Number of Multi-SP Uses H'00000000 (0): No multi-SP
H'00000001 (1): 2SP
H'00000002 (2): 4SP
Initial set-
ting
1336 331B Multi-SP Uses H'00000000 (0): OFF
H'00000001 (1): ON
Advanced
function
setting
1338 331C HB ON/OFF H'00000000 (0): OFF
H'00000001 (1): ON
133A 331D MB Command Logic Switch-
ing (See note.)
H'00000000 (0): OFF
H'00000001 (1): ON
133C 331E Input Error Output H'00000000 (0): OFF
H'00000001 (1): ON
133E 331F Input Shift Type H'00000000 (0): Temperature input 1-point shift
H'00000001 (1): Temperature input 2-point shift
1340 3320 MV at Stop and Error Addi-
tion
H'00000000 (0): OFF
H'00000001 (1): ON
1342 3321 ST Stable Range H'00000001 to H'0000270F (0.1 to 999.9)
1344 3322 RT H'00000000 (0): OFF
H'00000001 (1): ON
1346 3323 HS Alarm Use H'00000000 (0): OFF
H'00000001 (1): ON
1348 3324 LBA Detection Time H'00000000 to H'0000270F (0 to 9999)
134A 3325 LBA Level H'00000001 to H'0000270F
(0.1 to 999.9 for TC/Pt universal input models)
(0.01 to 99.99 for Analog input models)
134C 3326 LBA Band H'00000000 to H'0000270F
(0.0 to 999.9 for TC/Pt universal input models)
(0.00 to 99.99 for Analog input models)
134E 3327 Soak Time Unit H'00000000 (0): Minutes
H'00000001 (1): Hours
1350 3328 Alarm SP Selection H'00000000 (0): Set point during SP ramp
H'00000001 (1): Set point
