SECTION 3 Communications Data for CompoWay/F and SYSWAY
3-8
Note 1: For Controllers with two event inputs (events 1 and 2), this cannot be set if the Number of Multi-SP
Uses parameter is set to 1 or 2.
Note 2: For Controllers with two event inputs (events 1 and 2), this cannot be set if the Number of Multi-SP
Uses parameter is set to 2.
Note 3: PRST (program start) can be set even when the program pattern is set to OFF, but the function
will be disabled.
Vari-
able
type
Ad-
dress
Parameter name Setting (monitor) value Level
C3 (83) 0016 Event Input Assignment 1
(See note 1.)
H'00000000 (0): None
H'00000001 (1): RUN/STOP
H'00000002 (2): Auto/manual switch
H'00000003 (3): Program Start (See note 3.)
H'00000004 (4): Direct/reverse operation
H'00000005 (5): None
H'00000006 (6): 100% AT execute/cancel
H'00000007 (7): 40% AT execute/cancel
H'00000008 (8): Setting change enable/disable
H'00000009 (9): Communications writing enable/disable
H'0000000A (10): Alarm latch cancel
Initial set-
ting
C3 (83) 0017 Event Input Assignment 2
(See note 2.)
H'00000000 to H'0000000A (0 to 10)
* Same as for Event Input Assignment 1.
C3 (83) 0018 Event Input Assignment 3 H'00000000 to H'0000000A (0 to 10)
* Same as for Event Input Assignment 1.
C3 (83) 0019 Event Input Assignment 4 H'00000000 to H'0000000A (0 to 10)
* Same as for Event Input Assignment 1.
C3 (83) 001A Multi-SP Uses H'00000000 (0): OFF
H'00000001 (1): ON
Advanced
function
setting
C3 (83) 001B SP Ramp Time Unit H'00000000 (0): EU/second
H'00000001 (1): EU/minute
H'00000002 (2): EU/hour
C3 (83) 001C SP Ramp Set Value H'00000000 (0): OFF
H'00000001 to H'0000270F (1 to 9999)
Adjust-
ment
C3 (83) 001D Standby Sequence Reset H'00000000 (0): Condition A
H'00000001 (1): Condition B
C3 (83) 001E Auxiliary Output 1 Open in
Alarm
H'00000000 (0): Close in alarm
H'00000001 (1): Open in alarm
Advanced
function
setting
C3 (83) 001F Alarm 1 Hysteresis H'00000001 to H'0000270F
(0.1 to 999.9 for TC/Pt universal input models)
(0.01 to 99.99 for Analog input models)
Initial set-
ting
