Omron E5CC-B-800 - Page 23

E5EC-800/E5EC-B-800/E5AC-800
23
E5AC-800 48 × 96 mm
* Position proportional control model.
Note: Draw-out-type models of the E5AC-800 are available. Ask your OMRON representative for details.
Control output 1 Control output 2
Auxiliary
output
Communications
Heater
burnout
Event
inputs
Power supply
voltage
Model
Relay output -
One
---
100 to 240 VAC
E5AC-RX1ASM-800
Voltage output - E5AC-QX1ASM-800
Linear current output - E5AC-CX1ASM-800
Relay output -
Three
E5AC-RX3ASM-800
Voltage output - E5AC-QX3ASM-800
Linear current output - E5AC-CX3ASM-800
Relay output -
One
24 VAC/VDC
E5AC-RX1DSM-800
Voltage output - E5AC-QX1DSM-800
Linear current output - E5AC-CX1DSM-800
Relay output -
Three
E5AC-RX3DSM-800
Voltage output - E5AC-QX3DSM-800
Linear current output - E5AC-CX3DSM-800
Relay output -
RS-485
One
Two
100 to 240 VAC
E5AC-RX3ASM-808
Voltage output - E5AC-QX3ASM-808
Relay output -
24 VAC/VDC
E5AC-RX3DSM-808
Voltage output - E5AC-QX3DSM-808
Relay output -
-Four
100 to 240 VAC
E5AC-RX3ASM-810
Voltage output - E5AC-QX3ASM-810
Relay output -
24 VAC/VDC
E5AC-RX3DSM-810
Voltage output - E5AC-QX3DSM-810
Linear current output -
RS-485 - Two
100 to 240 VAC E5AC-CX3ASM-804
Linear current output - 24 VAC/VDC E5AC-CX3DSM-804
Relay output (Open)* Relay output (Close)* -
-
-
-
100 to 240 VAC
E5AC-PR0ASM-800
Relay output (Open)* Relay output (Close)*
Two
E5AC-PR2ASM-800
Relay output (Open)* Relay output (Close)* RS-485 Two E5AC-PR2ASM-804
