Optional Products (Order Separately)
USB-Serial Conversion Cable
Communications Conversion Cable
Note: Always use this product together with the E58-CIFQ2.
This Cable is used to connect to the bottom-panel Setup Tool
port.
Current Transformers (CTs)
*Lead wires are included with these CTs. If UL certification is required, use
these CTs.
Mounting Adapter
Note: This Mounting Adapter is provided with the Digital Temperature
Controller.
Waterproof Packing
Note: This Waterproof Packing is provided with the Digital
Temperature Controller.
Draw-out Jig
CX-Thermo Support Software
Note: CX-Thermo version 4.62 or higher is required for the E5GC.
For the system requirements for the CX-Thermo, refer to
information on the EST2-2C-MV4 on the OMRON website
(www.ia.omron.com).
Terminal Covers (for E5GC-@6)
Note: This Terminal Covers is provided with the Digital Temperature
Controller.
Model
E58-CIFQ2
Model
E58-CIFQ2-E
Hole diameter Model
5.8 mm E54-CT1
5.8 mm E54-CT1L*
12.0 mm E54-CT3
12.0 mm E54-CT3L*
Model
Y92F-53 (2pcs)
Model
Y92S-P12
Model
Y92F-55
Model
EST2-2C-MV4
Model
E53-COV27

Omron E5CC Specifications

General

Number of Display Digits	4 digits
Number of Control Outputs	1
Control Method	ON/OFF
Input Type	Thermocouple, RTD, Analog voltage, Analog current
Supply Voltage	100 to 240 VAC
Output Type	Relay, Voltage, Current
Display Type	LCD
Size	48 x 48 mm
Mounting Method	Panel mount
Control Output	Relay, Voltage, Current
Alarm Output	Relay
Communication	RS-485
Ambient Operating Temperature	-10 to 55°C
Ambient Operating Humidity	25% to 85% RH
Protection Rating	IP66
