E5CD-800
4
Optional Products (Order Separately)
Terminal Covers
Note: The E53-COV10 cannot be used.
Refer to page 13 for the mounted dimensions.
Waterproof Packing
Note: This Waterproof Packing is provided with the Digital
Temperature Controller.
Current Transformers (CTs)
*Lead wires are included with these CTs. If UL certification is required, use
these CTs.
Adapter
Note: Use this Adapter when the panel has already been prepared for
an E5B@ Controller.
Waterproof Cover
Mounting Adapter
Note: This Mounting Adapter is provided with the Digital Temperature
Controller.
DIN Track Mounting Adapter
Front Covers
Draw-out Jig
Model
E53-COV17
E53-COV23 (3pcs)
Model
Y92S-P8
Hole diameter Model
5.8 mm E54-CT1
5.8 mm E54-CT1L*
12.0 mm E54-CT3
12.0 mm E54-CT3L*
Model
Y92F-45
Model
Y92A-48N
Model
Y92F-49
Model
Y92F-52
Type Model
Hard Front Cover Y92A-48H
Soft Front Cover Y92A-48D
Model
Y92F-58
To Next Page
