E5CD-800
3
Model Number Legend and Standard Models
Model Number Legend
E5CD-@@ 2 @ DM-@@@ (Example: E5CD-RX2ADM-800)
−−
−−−
A BC DE F
Heating and Cooling Control
Using Heating and Cooling Control
A Control Output Assignment
An auxiliary output is used as the cooling control output.
B Control
If PID control is used, you can set PID control separately for heating and cooling.
This allows you to handle control systems with different heating and cooling response characteristics.
List of Models
Model
A B C D E F
Meaning
Control outputs
1 and 2
No. of
auxiliary
outputs
Power
supply
voltage
Terminal
type
Input
type
Options
E5CD 48 × 48 mm
Control output 1 Control output 2
RX Relay output None
QX
Voltage output
(for driving SSR)
None
2 2 independent outputs
A 100 to 240 VAC
D 24 VAC/DC
D Screw terminal blocks, draw-out structure
M Universal input
HB alarm and HS alarm
Communications
800 --- ---
802 1 RS-485
Model
E5CD-RX2ADM-800
E5CD-RX2DDM-800
E5CD-RX2ADM-802
E5CD-RX2DDM-802
E5CD-QX2ADM-800
E5CD-QX2DDM-800
E5CD-QX2ADM-802
E5CD-QX2DDM-802
