E5CN
E5CN

PARAMETERS
Parameters related to setting items for each level are marked in
boxes in the flowcharts and brief descriptions are given as
required. At the end of each setting item, press the mode key to
return to the beginning of each level.
Display
E5CN E5GN
No. 1 display
No. 2 display
No. 1 display
No. 2 display
Password input
set value “1201”
Advanced function
setting level
Calibration level
Password input
set value “-169”
Control stops.
Initial setting level
Less than 1 second
key
Communications
setting level
Power ON
Operation level
1 second min.
+key
Protect level
Control in progress
Control stopped
Adjustment level
1 second
min.
key
1 second
min.
key
3 second min.
key
Level change
Less than 1 second
key
Operation Level
PV
PV/SP
Add in the “additional
PV display” parameter.
Multi-SP
Set point during SP ramp
Heater current value monitor
Run/stop
Alarm value 1
Upper-limit
alarm value 1
Lower-limit
alarm value 1
Set either of
these parameters.
Alarm value 2
Upper-limit
alarm value 2
Lower-limit
alarm value 2
Set either of
these parameters.
MV monitor (heat)
MV monitor (cool)
Current value
monitor of HBA
Select SP.

: RUN

:STOP
Power ON

Omron E5CN Specifications

General

Communication	RS-485 (optional)
Mounting	Panel Mount
Control Method	ON/OFF
Input Type	Thermocouple, RTD
Supply Voltage	100 to 240 VAC
Output Type	Relay, Voltage (for driving SSR), Current
Display Type	7-segment LED
Size	48 x 48 mm
Control Output	Relay, Voltage (for driving SSR), Current
Alarm Output	1 or 2 outputs
Dimensions	48 x 48 x 78 mm
Ambient Operating Temperature	-10 to 55°C
Protection Rating	IP66
