E5CS-X E5CS-X
38
J ACCESSORIES (ORDER SEPARATELY)
Description Part number
Protective cover Hard plastic; protects front panel against dust, dirt and water drops Y92A-48
Panel mounting adapter Replacement for one supplied with each unit Y92F-30
Specifications
Part number
E5CS-j1KJX E5CS-j1PX E5CS-j1GX
Sensor input type Thermocouple
Type J (IC) and Type K (CA)
Platinum RTD (Pt: 100Ω)
DIN or JIS standard
Thermistor
(interchangeable type)
Supply voltage 100 to 240 VAC, 50/60 Hz; operates on 85 to 110% of rated voltage
Power consumption Approx. 7 VA
Control Contact
Type SPDT relay
output
Max. load 3 A, 250 VAC (resistive load)
Voltage Logic load 12 VDC, 20 mA with short-circuit protection
Hysteresis 0.2% of full scale during ON/OFF control action
Response
Output 2 seconds for output to change
time
Display 2 seconds for displayed indication to change
Service life
Mechanical 10 million operation minimum with contact output
Electrical 100,000 operations minimum with contact output
Alarm output
Type SPST-NO relay
Max. load 1 A, 250 VAC (resistive load)
Setting range Absolute value alarm: Same as control output setting range
Others: 0 to full scale
Setting accuracy Set value coincides with indicated value, so no relative error exists
Indication accuracy ±0.5% of full scale, ±1 digit max.
Display range –999 to 999 (limited to input type)
Control
Type ON/OFF and PID with automatic tuning of proportional band, switch selectable
modes
Proportional band 3% to 20% (in PID mode) automatically adjusted according to the rise time of the
controlled system
Reset time 4 minutes (in PID mode)
Rate time 0.4 minutes (in PID mode)
Proportional period 2 or 20 seconds, switch selectable
Sampling period 500 ms
Materials Plastic case
Mounting Fits 1/16 DIN panel cutout; includes panel mounting adapter
Connections Screw terminals
Weight 170 g (6 oz.) without mounting adapter
Enclosure ratings
Front panel IP50, NEMA 4 with optional Y92A-48N waterproof cover
Rear panel IP30
Terminals IP00
Approvals
UL Recognized, File Number E68481
CSA Certified, File Number LR59623
CE Conforms to EN61010-1
Ambient temperature
Operating –10°C to 55°C (14°F to 131°F)
Storage –25°C to 65°C (–13°F to 149°F)
Humidity 35 to 85% RH
Insulation resistance 20 MΩ minimum at 500 VDC
Dielectric strength 2,000 VAC, 50/60 Hz for 1 minute between current-carrying terminals of different polarity
Vibration
Mechanical durability 10 to 55 Hz, 0.75 mm (0.03 in) double amplitude in X, Y, and Z directions for 2 hours each
Malfunction durability 2 to 55 Hz, 2 G in X, Y, and Z directions for 10 minutes each
Shock
Mechanical durability 30 m/s
2
, in 6 directions, 3 times each
Malfunction durability 100 m/s
2
, in 6 directions, 3 times each
