Omron E5DC-RX0ASM-015 Manual

E5GC
15
E54-CT3 Accessories
• Armature
12 dia.
2.36 dia.
Two, M3 (depth: 4)
40 × 40
30
9
30
8
Filler
(epoxy)
Case
(PBT)
15
40
Approx. 3 dia.
18
(22)
Approx. 6 dia.
Plug
Armature
Lead
E54-CT3
Connection Example
•Plug
Thru-current (Io) vs. Output Voltage (Eo)
(Reference Values)
E54-CT3 or E54-CT3L
Maximum continuous heater current: 120 A (50/60 Hz)
(Maximum continuous heater current for an OMRON
Digital Temperature Controller is 50 A.)
Number of windings: 400±2
Winding resistance: 8±0.8
Ω
Thru-current (Io) A (r.m.s.)
1 10 100mA 1 10 100
1,000A
100V
Frequency: 50 Hz
Distortion
factor
10%
3%
1%
1kΩ
100Ω
50Ω
RL=10Ω
500Ω
∞
10
1
100mV
10
1
100μV
10
Output voltage (Eo) V (r.m.s.)
Filler (epoxy)
Case (PBT)
Cable (AWG18)
12.0
dia.
30
40
8
40 15
100±5
8
Two, M3
(depth: 4)
30
E54-CT3L
