A Appendices
A - 36
E5@C Digital Temperature Controllers User’s Manual (H174)
Remote SP Upper limit rsph Temperature input: Input setting range lower limit to
Input setting range upper limit
1300 EU
Analog input: Scaling lower limit to Scaling upper
limit
100
Remote SP lower limit rspl Temperature input: Input setting range lower limit to
Input setting range upper limit
−200 EU
Analog input: Scaling lower limit to Scaling upper
limit
0
SP Tracking
sptr OFF, ON off, on OFF None
PV Dead Band p-db 0 to 9999 0 EU
Manual MV Limit
Enable
manl OFF, ON off, on OFF None
Direct Setting of
Position Proportional
MV
pmvd OFF, ON off, on OFF None
PV Rate of Change
Calculation Period
pvrp 1 to 999 20 Sampling
period
Heating/Cooling Tuning
Method
hctm 0: Same as heating control
1: Linear
2: Air cooling
3: Water cooling
0None
Minimum Output
ON/OFF Band
ompw 0.0 to 50.0 1.0 %
PF Setting pf OFF: OFF
RUN: RUN
STOP: STOP
R-S: RUN/STOP
AT-2: 100% AT execute/cancel
AT-1: 40% AT execute/cancel
LAT: Alarm Latch Cancel
A-M: Auto/manual
PFDP: Monitor/setting item
SHFT: Digit Shift Key
off
run
stop
r-s
at-2
at-1
lat
a-m
pfdp
shft
SHFT None
Monitor/Setting Item 1 pfd1 0: Disabled
1: PV/SP/Multi-SP
2: PV/SP/MV (valve opening for
Position-proportional Models)
3: PV/SP/Soak time remain
4: Proportional band (P)
5: Integral time (I)
6: Derivative time (D)
7: Alarm value 1
8: Alarm value upper limit 1
9: Alarm value lower limit 1
10: Alarm value 2
11: Alarm value upper limit 2
12: Alarm value lower limit 2
13: Alarm value 3
14: Alarm value upper limit 3
15: Alarm value lower limit 3
16: Alarm value 4
17: Alarm value upper limit 4
18: Alarm value lower limit 4
19: PV/SP/Internal SP
20: PV/SP/Alarm value 1
21: Proportional Band (Cooling) (C-P)
22: Integral Time (Cooling) (C-I)
23: Derivative Time (Cooling) (C-D)
1None
Monitor/Setting Item 2 pfd2
Same as Monitor/Setting Item 1. 0 None
Mon
itor/Setting Item 3 pfd3 Same as Monitor/Setting Item 1. 0 Non
e
Monitor/Setting Item 4 pfd4 Same as Monitor/Setting Item 1. 0 None
Parameters Characters Setting (monitor) value Display Default Unit
000
000
000
000
000
000
000
000
