5 Advanced Operations

5 - 52

E5@C Digital Temperature Controllers User’s Manual (H174)

• Setting the Extraction of Square Root Low-cut Point

Press the M Key several times in the Adjustment Level to dis-

play sqrp (Extraction of Square Root Low-cut Point).

Adjustment Level

Press the U or D Key to set the value to 10.0.

The default is 0.0 (%).

0.0

sqrp

Extraction of

Square Root

Low-cut Point

10.0

sqrp
