5 Advanced Operations
5 - 68
E5@C Digital Temperature Controllers User’s Manual (H174)
(4) Selecting Input Assignments
Select the input assignment for the work bit logic operation from the following settings.
* The event inputs that can be used depend on the Digital Controller model.
Parameter name Setting range
Work Bit 1 Input Assignment A
0. Always OFF
1. Always ON
2. ON for one cycle when power is turned
ON
3. Event input 1 (external input)*
4. Event input 2 (external input)*
5. Event input 3 (external input)*
6. Event input 4 (external input)*
7. Event input 5 (external input)*
8. Event input 6 (external input)*
9. Alarm 1
10. Alarm 2
11. Alarm 3
12. Alarm 4
13. Control output (heating)
14. Control output (cooling)
15. Input error
16. RSP input error
17. HB (heater burnout) alarm
18. HS alarm
19. Auto/Manual
20. RUN/STOP
21. RSP/LSP
22. Program start
23. AT Execute/Cancel
24. SP ramp operating
25. Multi-SP No. switching bit 0
26. Multi-SP No. switching bit 1
27. Multi-SP No. switching bit 2
28. Program end output
29. Work bit 1
30. Work bit 2
31. Work bit 3
32. Work bit 4
33. Work bit 5
34. Work bit 6
35. Work bit 7
36. Work bit 8
Work Bit 1 Input Assignment B Same as for work bit 1 input assignment A
Work Bit 1 Input Assignment C Same as for work bit 1 input assignment A
Work Bit 1 Input Assignment D Same as for work bit 1 input assignment A
to to
Work Bit 8 Input Assignment D Same as for work bit 1 input assignment A
To Next Page
