6 Parameters
6 - 74
E5@C Digital Temperature Controllers User’s Manual (H174)
The alarm 1, 2, 3, or 4 output is prevented from turning OFF until after the delay times set in these
parameters have elapsed.
a1of
Alarm 1 OFF Delay
Alarm 1 must be assigned, and the alarm 1 type
must not be 0, 12, or 13.
a2of
Alarm 2 OFF Delay
Alarm 2 must be assigned, and the alarm 2 type
must not be 0, 12, or 13.
a3of
Alarm 3 OFF Delay
Alarm 3 must be assigned, and the alarm 3 type
must not be 0, 12, or 13.
a4of
Alarm 4 OFF Delay
Alarm 4 must be assigned, and the alarm 4 type
must not be 0, 12, or 13.
Set the time for which the OFF delay is to be enabled.
To disable the OFF delay, set 0.
Related Parameters
Alarm 1 to 4 Type (Initial Setting Level): Page 6-48
mVse
MV at Stop and Error Addition
Control must be set to 2-PID control.
This parameter sets whether or not the MV at Stop and MV at PV Error parameters are to
be displayed.
Related Parameters
MV at Stop (Adjustment Level): Page 6-32
MV at PV Error (Adjustment Level): Page 6-33
Function
Setting
Setting range Unit Default
0 to 999 Seconds 0
See
See
000
Function
Setting
Setting range Default
on: Displayed, off: Not displayed off
See
See
