A - 3
A Appendices
E5@C Digital Temperature Controllers User’s Manual (H174)
A-1 Specifications
A
A-1-1 Ratings
*1 For input setting ranges, refer to A-7 Sensor Input Setting Range, Indication Range, Control Range.
*2 When connecting the ES2-HB/THB, connect it 1:1.
*3 With the E5CC, you cannot select a relay output or linear current output for control output 2.
*4 The E5CC-U, E5CC-B, E5EC-B, E5DC, E5DC-B, and E5GC do not have control output 2.
*5 The 0 to 50 mV range can be used only for E5CC-U Digital Controllers and only if they are manufactured in May 2014 or
later (version 2.2 or higher).
 HB and HS Alarms
(E5@C Models with HB and HS Alarms)
*1 HB alarms are not detected and the heater power is not measured if the ON time for the control output for
heating is 100 ms or less (30 ms or less if the control period is 0.1 or 0.2 s).
*2 HS alarms are not detected and the leakage power is not measured if the ON time for the control output
for heating is 100 ms or less (35 ms or less if the control period is 0.1 or 0.2 s).
Control method ON/OFF or 2-PID control (with autotuning)
Setting method Digital setting using front panel keys
Indication method 11-segment digital displays and individual indicators
Other functions Depend on the model
Ambient temperature
−10 to 55°C (with no condensation or icing), For 3-year warranty: Mounted individually at −10
to 50°C (with no condensation or icing)
Ambient humidity 25% to 85%
Storage temperature −25 to 65°C (with no condensation or icing)
Altitude 2,000 m max.
Recommended fuse T2A, 250 VAC, time lag, low shut-off capacity
Installation environment Overvoltage Category II, Pollution Class 2 (EN/IEC/UL 61010-1)
Max. heater current
50 A AC
Input current readout
accuracy
±5% FS ±1 digit max.
Heater burnout alarm
setting range
0.1 to 49.9 A (0.1 A units)
0.0 A: Heater burnout alarm output turns OFF.
50.0 A: Heater burnout alarm output turns ON.
Min. detection ON time
*1
: 30 ms for a control period of 0.1 s or 0.2 s
100 ms for a control period of 0.5 s or 1 to 99 s
Heater short alarm
setting range
0.1 to 49.9 A (0.1 A units)
0.0 A: Heater short alarm output turns ON.
50.0 A: Heater short alarm output turns OFF.
Min. detection OFF time
*2
: 35 ms for a control period of 0.1 s or 0.2 s
100 ms for a control period of 0.5 s or 1 to 99 s
Supply voltage 100 to 240 VAC, 50/60 Hz 24 VAC, 50/60 Hz/24 VDC
