Simplicity on the Worksite Solutions Guide for FAQs: E5CC/E5EC
Setting Temperature Alarms
4-7
Setting Temperature Alarms
You set the alarm value in the Operation Level.
2 Setting the Alarm Value
Setting Alarm Type 1, 4, or 5 (Uppe
r
-limit and
Lower-limit Alarms or Upper-limit and Lower-limit
Range Alarms)
Press the (Level)
Key for at least 1
second.
The following procedure continues on from the
procedure to set the Alarm Type parameter (Initial
Setting Level).
Start here if you j ust turned
ON the power supply.
Setting Alarm Type 2, 3, 6, 7, 8, 9,10, o
r
11 (Upper-limit Alarms and Lower-limit
Alarms)
Press the (Mode) Key
several times to display
al-1 (AL-1).
Press the Key for at least 1 second.
1
Initial Setting Level
Operation Level
Change the parameter with the Ke y.
2
Press the (Mode) Key
several times to display
al1h (AL1H).
