Temperature Controller Characteristics
Setting accuracy* + 0.3% of set value or ±1°C, whichever ± 1 digit max.
Set value coincides with the indicated value, because no relative error exists between both values.
Indication accuracy
Hysteresis (during ON/OFF
control action)
0.0° to 999.9 °C/° F (in units of 0.1 °)
Proportional band 0.0° to 999.9 °C/° F (in units of 0.1 °)
Integral time (Reset time) 0 to 3,999 s (in units of 1 s)
Derivative time (Rate time) 0 to 3,999 s (in units of 1 s)
Alarm output setting range Thermocouple: –999 ° to 9,999 °C/°F
Platinum resistance thermometer (Pt100): –99.9 ° to 999 °C/°F
Control period Pulse output: 1 to 99 s (in units of 1 s)
Sampling period 500 ms
Output refresh period Pulse output: 500 ms
Current output: 500 ms
Display refresh period 500 ms
Input shift Thermocouple: –999 ° to 9,999 °C/°F
Platinum resistance thermometer (Pt100): –99.9 ° to 999.9 °C/°F
Insulation resistance 20 M Ω min. (at 500 VDC) (measured with a Control Output Unit attached)
Dielectric strength 2,000 V AC 50/60 Hz for 1 minute between terminals of dif ferent polarity (measured with a Control
Output Unit attached)
Vibration Malfunction durability: 2 to 55 Hz, 2G 10 min each in X, Y , and Z directions
Mechanical durability: 10 to 55 Hz, 0.75-mm double amplitude 2 hrs each in X, Y , and Z directions
Shock Malfunction durability: 100 m/s
2
3 times each in 6 directions
Mechanical durability: 300 m/s
2
3 times each in 6 directions
Ambient temperature Operating:–10° to 55 °C
Storage: –25°
to 65 °C
Humidity 35% to 85%
Memory protection Non-volatile memory
Enclosure ratings Front panel controls: IEC standard IP50 (dust-proof)
Rear case: IEC standard IP20
Terminals: IEC standard IP00
Weight 300 g
*The accuracy of U at temperatures from –150° to 400°C (–240°C to 700°F) is ±2°C (±3.6°F) ±1 digit. Accuracy is reduced below –150°C
(–240°F).
The accuracy of R and S from 0 ° to 200 °C (0° to 400 °F) is ±3°C (±5.4° F) ± 1 digit.
Output Unit Characteristics
Relay unit life expectancy Mechanical: 10,000,000 operations min.
Electrical: 100,000 operations min.
Current Transformer Characteristics
Max. heater current 50 A, single-phase
Indication accuracy of heater current ± 5% of full scale ± 1 digit max.
Heater current setting range 0.1 to 49.9 A* (in units of 0.1 A)
Min. detectable ON time 200 ms**
*Heater burnout is not detected when current is set to 0.0 A; the burnout alarm will be automatically turned ON when current is set to 50.0
**When the control output is ON for less than 200 ms, heater burnout is not detected and heater current is not measured.
