3 Communications Data for CompoWay/F
3 - 14
E5@C Digital Temperature Controllers Communications Manual (H175)
*1 P.END (program end output) can be set even when the program pattern is set to OFF, but the function will
be disabled.
*2 Selection is possible only with the E5CC-U, E5DC, and E5GC and only when there is a control output that is
a linear current output.
(The E5CC-U must be manufactured in May 2014 or later (version 2.2 or higher) and the E5DC must be
manufactured in July 2014 or later (version 2.2 or higher).)
Variable
type
Address Parameter name Setting (monitor) value Level
C3 (83) 004E Control Output 1
Assignment
Control output 1 is a relay output or voltage output (for
driving SSR):
H'00000000 (0): Not assigned.
H'00000001 (1): Control output (heating)
H'00000002 (2): Control output (cooling)
H'00000003 (3): Alarm 1
H'00000004 (4): Alarm 2
H'00000005 (5): Alarm 3
H'00000006 (6): Alarm 4
H'00000007 (7): Heater alarm
H'00000008 (8): HB alarm
H'00000009 (9): HS alarm
H'0000000A (10): Input error
H'0000000B (11): RSP input error
H'0000000C (12): Program end output
*1
H'0000000D (13): RUN output
H'0000000E (14): Integrated alarm
H'0000000F (15): Work bit 1
H'00000010 (16): Work bit 2
H'00000011 (17): Work bit 3
H'00000012 (18): Work bit 4
H'00000013 (19): Work bit 5
H'00000014 (20): Work bit 6
H'00000015 (21): Work bit 7
H'00000016 (22): Work bit 8
When control output 1 is a linear current output:
H'FFFFFFFB (−5): Simple transfer MV (cooling)
*2
H'FFFFFFFC (−4): Simple transfer MV (heating)
*2
H'FFFFFFFD (−3):Simple transfer PV
*2
H'FFFFFFFE (−2): Simple transfer ramp SP
*2
H'FFFFFFFF (−1): Simple transfer SP
*2
H'00000000 (0): Not assigned.
H'00000001 (1): Control output (heating)
H'00000002 (2): Control output (cooling)
Advanced
function
setting
C3 (83) 004F Control Output 2
Assignment
Control output 2 is a relay output or voltage output (for
driving SSR):
H'00000000 to H'00000016 (0 to 22)
* Same as for the Control Output 1 Assignment pa-
rameter.
When control output 2 is a linear current output:
H'00000000 to H'00000002 (0 to 2)
* *Same as for the Control Output 1 Assignment pa-
rameter, except for items marked with “*2.”
